Description

NU8976A99, HIER466665R0099, and HIEE320693R0001 are different identifiers for the same type of industrial automation module from ABB (the correspondence between the main model and spare parts/order numbers). They are mainly used in ABB Advant OCS and Symphony DCS distributed control systems. The following is their complete information:

I. Technical Specifications1. Signal Processing CapabilityDigital Input (DI):Number of channels: 16 (isolated)Signal type: 24V DC (NPN/PNP compatible), 110V AC (optional)Response time: ≤1ms (switching state change detection)Isolation method: Electrical isolation between channels (1500V AC/1min)Digital Output (DO):Number of channels: 8Output type: Relay output (contact capacity 2A/250V AC)Protection function: Overload protection (self-recovering fuse)Analog Input (AI):Number of channels: 8Signal type: 4-20mA DC (default), 0-10V DC (configurable)Resolution: 12-bit (±0.1% FS accuracy, 25℃)Sampling rate: 10Hz/channel (adjustable through configuration)

2. Electrical and Communication ParametersPower Supply Requirements:Voltage: 24V DC (±10%), supports dual redundant power supplyPower Consumption: Typical 6W, Maximum 8W (under full load)Communication Interface:Bus Type: ABB A-BUS (system-specific backplane bus)Transmission Rate: 10 Mbps (real-time communication with controller)Compatibility: Compatible with Advant series controllers such as MC671/MC6723. Environmental and Mechanical CharacteristicsOperating Environment:Temperature: 0℃~+55℃ (operation), -20℃~+85℃ (storage)Humidity: 5%~95% (non-condensing)Interference Resistance: Compliant with IEC 61000-6-2 (industrial EMC)Physical Specifications:Dimensions: 105mm×215mm×175mm (W × H × D)Weight: Approximately 1.3kgInstallation Method: Advant OCS dedicated rack slot installation (not DIN rail)Protection Level: IP20 (cabinet installation)

2. Functional Features:1. Mixed Signal Integration: Simultaneously supports digital and analog signal processing, reducing the number of modules and saving cabinet space;2. Redundant Design: Supports power supply and communication bus redundancy, enhancing system reliability, suitable for critical control scenarios;3. Channel-level Diagnostics: Monitors disconnections, overrange, power failures, and other anomalies in real-time, triggering alerts through the controller;4. Wide Compatibility: Compatible with ABB Advant OCS/Symphony DCS legacy systems, for maintenance and upgrades of existing equipment.

3. Application ScenariosPetrochemical Industry: Reactor temperature/pressure data acquisition (AI), valve open/close control (DO);Power Industry: Auxiliary equipment status monitoring for generator sets (DI), pump start/stop control (DO);Metallurgical Industry: Rolling mill production line sensor signal processing, hydraulic system control signal output.
