Description

Based on the available information, 1VCR007346 G0032 is a product from ABB’s REF542PLUS series, which is a feeder protection and control device used in medium-voltage distribution systems. The following is its detailed information:



Product Name: ABB REF542PLUS 1VCR007346Rated

Voltage: 12kVRated Current: 630ABreaker

Capacity: 2500ACommunication

Interfaces: RS-232, RS-485,

EthernetOperating Temperature Range: -40°C to +70°

CDimensions: 600mm x 400mm x 200mm

Weight: 50kg

Functions:Protection

Functions: Provides feeder protection functions including overcurrent protection, short-circuit protection, overvoltage protection, undervoltage protection, frequency protection, and power protection. It can also realize transformer protection functions such as overload protection, excitation inrush protection, differential protection, and zero-sequence harmonic protection, as well as motor protection functions including overload protection, short-circuit protection, single-phase protection, and phase loss protection.Control Functions: Capable of switch control, breaker control, isolator control, and load control.Measurement Functions: Able to measure parameters such as voltage, current, power, and power factor.

Application areas: Suitable for industrial and civil buildings, power plants and substations, oil and gas, chemical, metallurgy, and various other scenarios requiring medium-voltage distribution systems.
