BENTLY 330180-90-05 3300 XL Proximitor Sensor（XIONGBA)

Name: BENTLY 330180-90-05 3300 XL Proximitor Sensor（XIONGBA)
SKU: 10948
Availability: InStock

$999.00

Brand Model: BENTLY 330180-90-05
Product Name: 3300 XL Proximitor Sensor (9.0 Metre System Length, Panel Mount with ATEX/CSA/IECEx Certification)
Warranty: 1 year (covers defects in materials/workmanship)
Size: 9.0 metres (29.5 feet) total system length
Weight: 0.43 kg (net weight)
Origin: United States
Inventory: Typically available via authorized distributors
Delivery Time: 2–4 weeks

Categories: BENTLY NEVADA

Need help?
Email: sales@fyplc.cn
Tel/WhatsApp: +86 173 5088 0093

Description
Reviews (0)

Description

Many products are not yet available—feel free to contact us for more options.

If there is a discrepancy between the product model and the displayed image, the model shall take precedence. For specific product photos, please reach out to us, and we will arrange on-site warehouse shots to confirm details.

With an extensive global warehouse network, there may be occasions where it takes a few hours to provide an accurate response. We appreciate your understanding, and rest assured we’ll address your inquiries as promptly as possible.

Product Overview

The BENTLY 330180-90-05 is a high-precision 3300 XL Proximitor Sensor engineered for real-time monitoring of rotating machinery health in hazardous environments. As the signal conditioning core of the 3300 XL 8 mm proximity transducer system, it processes inputs from compatible probes and extension cables to deliver accurate vibration and displacement measurements. With a 9.0-metre system length and panel-mount design, this sensor excels in applications requiring long-distance signal transmission while maintaining API 670 compliance and sub-millimeter accuracy.

Featuring gold-plated ClickLoc™ connectors and IP67-rated corrosion-resistant construction, the BENTLY 330180-90-05 ensures reliable performance in extreme environments (-51°C to +100°C) with minimal electromagnetic interference (EMI). Its modular design supports full interchangeability with 3300 XL probes and extension cables, eliminating the need for component calibration or matching. The sensor’s compact form factor enables high-density panel installations, making it ideal for retrofitting legacy systems or new industrial setups in explosive or wet environments.

Technical Specifications

Parameter Name	Parameter Value
Product Model	BENTLY 330180-90-05
Manufacturer	BENTLY NEVADA
Product Type	3300 XL Proximitor Sensor (8 mm System)
System Length	9.0 metres (29.5 feet)
Sensitivity	7.87 mV/μm (200 mV/mil)
Input Compatibility	3300/3300 XL 5 mm/8 mm proximity probes and extension cables
Output Signal	-20 VDC to -2 VDC proportional to target distance
Power Requirements	-17.5 VDC to -26 VDC (12 mA max current)
Impedance	75Ω (matched with extension cables)
Operating Temperature	-51°C to +100°C (-60°F to +212°F)
EMI/RFI Immunity	Compliant with CE standards without shielded conduit
Installation	Panel mount (4-hole pattern) with ATEX/CSA/IECEx certification for hazardous areas
Compliance	API 670 (4th edition), CE marked, ATEX 2014/34/EU, CSA, IECEx
Environmental Rating	IP67 (dust-tight and waterproof up to 1 meter immersion)

Main Features and Advantages

Explosion-Proof and Waterproof Design: The BENTLY 330180-90-05 is certified for use in explosive atmospheres (ATEX/IECEx) and features IP67 protection, making it suitable for offshore platforms, chemical processing plants, and other hazardous environments. Its PTFE-insulated core and stainless steel connectors resist corrosion, abrasion, and extreme temperatures, ensuring long-term reliability in harsh conditions.

Long-Distance Signal Integrity: The 9.0-metre system length minimizes signal degradation in multi-level equipment layouts, while the sensor’s EMI resistance ensures stable performance in high-electromagnetic environments like power plants. The ClickLoc™ connector system allows quick, secure connections without specialized tools, reducing downtime during installation or maintenance.

Precision Signal Conditioning: Achieves sub-millimeter accuracy by converting eddy current signals from probes into linear voltage outputs (200 mV/mil sensitivity), enabling precise detection of shaft misalignment, bearing wear, or thermal expansion. This level of precision is critical for predictive maintenance in turbines, compressors, and other high-value assets.

Global Compliance and Interchangeability: Backward compatibility with non-XL 3300 series components simplifies phased system upgrades, supporting mixed use with legacy 5 mm and 8 mm probes. The sensor’s ATEX/CSA/IECEx certifications ensure compliance with international safety standards, making it deployable in regulated industries worldwide.

Application Areas

The BENTLY 330180-90-05 is widely deployed in industries requiring advanced machinery diagnostics in hazardous or wet environments:

Oil and Gas: Monitors turbine shafts and compressors in offshore platforms, ensuring compliance with API 670 standards for vibration analysis. Its 9.0-metre length and IP67 rating facilitate multi-level equipment layouts in high-humidity or submerged areas.
Chemical Processing: Withstands corrosive environments in reactors and distillation units, providing reliable data for process optimization. The PTFE jacket resists chemical exposure, while ATEX certification allows use in explosive gas atmospheres.
Power Generation: Supports steam turbine diagnostics by measuring thermal expansion and bearing performance in real time. The sensor’s EMI resistance is critical in high-electromagnetic environments like power plants.
Mining and Heavy Industry: Integrates with high-speed rotating equipment in harsh conditions, reducing unplanned downtime. Its lightweight design (0.43 kg) aids routing in confined spaces.
