3500/22M 138607-01 is a speed/keyphasor module produced by Bently Nevada (now under Baker Hughes).

The company is a professional enterprise engaged in the sales of module spare parts for globally renowned brands (DCS systems) (robotic systems) (large servo control systems). The product range includes Distributed Control Systems (DCS), Programmable Logic Controllers (PLC), MOTOROLA MVME industrial modules, industrial control communication converters (Anybus), remote input/output modules (RTU), industrial computers (IPC), industrial touchscreens (HMI), human-machine interfaces, SCS (150, 68, 80 Pin), and AnyBus (Gateway). It has now become a global sales company for industrial automation spare parts and components.

Categories: BENTLY NEVADA

Need help?
Email: sales@fyplc.cn
Tel/WhatsApp: +86 173 5088 0093

Description
Reviews (0)

Description

Key FeaturesSpeed Measurement: Can receive pulse signals from magnetic or optical sensors, with a measurement range of 0 to 30,000 RPM and an accuracy of ±1 RPM.Key Phase Function: Provides a pulse signal once per revolution for phase reference and vibration analysis.Alarm Output: Features programmable overspeed or low-speed alarms, with relay output (normally open / normally closed).

Electrical CharacteristicsInput Channels: 1 speed input and 1 key signal input, input impedance ≥50kΩ.Output Signals: Equipped with 2 relay outputs (Alarm 1 / Alarm 2), contact capacity of 30VDC/2A, with optional 4-20mA or 0-10V analog output.Power Requirements: Operating voltage +24VDC (±10%), typical power consumption ≤5W.

Environmental AdaptabilityOperating Temperature: -30°C to +65°C.Protection Rating: IP20.Vibration/ Shock Resistance: Complies with API 670 standard.

Mechanical ParametersDimensions: Approximately 80mm × 120mm × 30mm.Mounting Method: Rail mounting, pluggable terminals.Communication and ConfigurationSystem Integration: Communicates with Bently Nevada 3500/Rack via 3500 framework interface, supports Modbus RTU or TCP/IP.Configuration Tool: Parameter settings are performed using Bently Nevada System 1 or 3500 Configuration Software.
