Description

Type: Depending on the application scenario, it can serve as either an auxiliary contact module for a circuit breaker or a power supply module.

Functions

As an auxiliary contact module: Used for ABB circuit breakers, it provides additional contact signals to obtain the current status information of the circuit breaker, such as open, closed, or fault. This module supports high-precision and high-speed monitoring capabilities and can quickly respond to changes in the circuit breaker status.

As a power supply module: It can be directly mounted on a printed circuit board, converting input AC or DC power into stable DC power to supply other circuits.

Technical Specifications

As an auxiliary contact module: Provides 2 normally open contacts and 2 normally closed contacts, with SPDT contact type, a rated current of 10A, a contact lifespan of 1 million operations, an operating temperature of -25°C to +70°C, protection level of IP20, and rail mounting installation.

Technical Specifications

1. As an auxiliary contact module: Provides 2 normally open contacts and 2 normally closed contacts, with SPDT contact type, a rated current of 10A, a contact lifespan of 1 million operations, an operating temperature of -25°C to +70°C, protection level of IP20, and rail mounting installation.

2. As a power supply module: According to output accuracy, it can be divided into regulated output and adjustable output (AC-DC power supply modules), unregulated output, regulated output, and adjustable output (DC-DC power supply modules); according to isolation voltage, it can be classified into different levels, such as AC-DC power supply modules with isolation voltages of 2000V, 3000V, 4000V, etc., and DC-DC power supply modules with isolation voltages of 1000V, 1500V, 3000V, 6000V, etc.

Application Areas

1. As an auxiliary contact module: Widely used in the field of industrial automation, playing a key role especially in robotics, automated production lines, and equipment control.

2. As a power supply module: Suitable for various applications, including communication power supplies such as program-controlled switches, transmission equipment, data centers, and mobile base stations; industrial control power supplies, such as automated production lines, robots, sensors, and actuators; computer and peripheral power supplies, and consumer electronics power supplies.
