A-B-1756-IF16-A High Torque Bipolar Stepper Motor Analog Input Module

Type	Analog Input Module
Number of Channels	16
Input Signal Range	±10 V, 0 – 20 mA, 4 – 20 mA
Resolution	16 – bit

Categories: OTHER

Need help?
Email: sales@fyplc.cn
Tel/WhatsApp: +86 173 5088 0093

Description
Reviews (0)

Description

A-B-1756-IF16-A High Torque Bipolar Stepper Motor Analog Input Module

A-B-1756-IF16-A

This analog input module is not just a device for signal acquisition; it’s a sophisticated solution that combines advanced technology with rugged design. With its ability to handle up to 16 analog input channels, the Allen – Bradley 1756 – IF16 – A offers versatility and scalability, allowing industrial operators to tailor their automation setups to meet specific process requirements. Its high – precision signal conversion capabilities ensure that the data it provides is reliable and accurate, enabling informed decision – making in real – time industrial operations.

Label	Specification
Model Number	1756 – IF16 – A
Brand	Allen – Bradley (Rockwell Automation)
Type	Analog Input Module
Number of Channels	16
Input Signal Range	±10 V, 0 – 20 mA, 4 – 20 mA
Resolution	16 – bit
Accuracy	±0.1% of full – scale
Input Impedance	≥10 MΩ for voltage inputs, ≤250 Ω for current inputs
Isolation	Channel – to – channel and channel – to – ground isolation
Communication Interface	Backplane communication with ControlLogix chassis
Mounting	Installable in ControlLogix chassis slots
Weight	Approximately 0.45 kg
Certifications	CE, UL, CSA, FM
Dimensions	171.45 x 71.12 x 44.45 mm
Operating Temperature	0°C – 60°C

A-B-1756-IF16-A

The Allen – Bradley 1756 – IF16 – A showcases numerous functional strengths and design advantages that set it apart in the industrial automation market. Its 16 – bit resolution ensures that even the slightest changes in analog signals are accurately captured, providing detailed and precise data for process control. The module’s wide range of supported input signal types, including voltage and current signals, makes it adaptable to various industrial sensors and measurement devices, eliminating the need for multiple specialized modules in many applications.

Built with high – quality components and advanced isolation technology, the Allen – Bradley 1756 – IF16 – A offers excellent noise immunity, ensuring reliable operation even in electrically noisy industrial environments. The channel – to – channel and channel – to – ground isolation prevents electrical interference between different input channels, enhancing the accuracy and stability of signal measurement. Its seamless integration with the ControlLogix backplane enables fast and efficient data transfer to the control system, allowing for real – time monitoring and response. Operators benefit from the ease of configuration using Rockwell Automation’s programming software, which allows for quick setup of input ranges, scaling, and filtering parameters, streamlining the commissioning process and reducing downtime.

A-B-1756-IF16-A

The Allen – Bradley 1756 – IF16 – A finds extensive applications across diverse industries. In the oil and gas industry, it is used to monitor crucial process variables such as pipeline pressure, wellhead temperature, and fluid flow rates. By accurately capturing these analog signals, the module provides the data necessary for operators to optimize production, ensure safety, and prevent costly equipment failures.
