AB 80190-580-51 Driver Processor Input/Output Module

80190-580-51

The Allen – Bradley 80190 – 580 – 51 is a digital module that serves a dual – purpose function. It can operate as a digital input module, meticulously collecting and relaying digital signals from various sensors and devices in the industrial environment. This makes it an essential part of systems that need to monitor the status of equipment, such as the on – off state of machinery, the position of valves, or the status of limit switches.

Technical Highlights Table：

Label	Specification
Model Number	80190 – 580 – 51
Brand	Allen – Bradley
Type	Digital Input/Output Module
Input Voltage	10 – 30 V DC
Operating Temp	– 25 °C to + 60 °C (Operating), – 40 °C to + 85 °C (Storage)
Communication Method	Supports Modbus RTU (for data exchange with other control devices)
Mounting	Compact design for easy installation in various industrial setups
Weight	Approximately 0.3 kg (for the input module version as per some sources)
Certifications	Complies with relevant industrial standards ensuring quality and safety
Dimensions	100mm x 60 mm x 70 mm (taking up minimal space)
Channels	16 channels (each can be configured as sink or source for output, and for input, supports accurate signal detection)
Current Handling per Channel	Up to 10 mA (for accurate data acquisition in input mode)
Power Consumption	2 W (for efficient operation)

80190-580-51

Functional Strengths & Design Advantages​

The Allen – Bradley 80190 – 580 – 51 has been engineered with precision to offer top – notch performance. As a digital input module, its ability to accurately detect and process digital signals is remarkable. With 16 channels, it can monitor multiple inputs simultaneously, providing a comprehensive view of the industrial process. Each channel’s capacity to handle up to 10 mA of current ensures that even weak signals are accurately captured, enabling reliable monitoring.​

When operating as a digital output module, it offers great flexibility. The 16 channels can be configured as either sink or source outputs, allowing for seamless control of different types of industrial devices. Whether it’s powering solenoids to actuate valves, controlling relays to switch electrical circuits, or lighting up indicator lights to convey the status of equipment, the 80190 – 580 – 51 does it with precision.​

In terms of build quality, this module is built to last. It can withstand the harsh conditions commonly found in industrial settings. The wide operating temperature range, from – 25 °C to + 60 °C during operation and an even broader range during storage, means it can function reliably in extreme cold or hot environments. Its compact size and lightweight design, with dimensions of 100mm x 60 mm x 70 mm and weighing only about 0.3 kg, make it easy to install in tight spaces and integrate into existing control systems without much hassle.

Setup & Service Guidance
​

80190-580-51

Installing the Allen – Bradley 80190 – 580 – 51 requires careful consideration. When mounting the module, ensure that it is placed in an area with proper ventilation to prevent overheating, especially since it operates within a certain power consumption range of 2 W. If it’s being installed in a rack – mounted system, make sure the rack is securely grounded to protect against electrical surges. The module’s compact size allows for easy installation in tight spaces, but proper alignment and connection are crucial.
