For engineers and plant managers seeking to optimize their automation setups, the MVI56-PDPMV1 stands out as a robust, proven solution. Its design prioritizes compatibility with existing infrastructure while delivering the speed and precision required for modern industrial environments. By seamlessly integrating into ControlLogix racks and supporting up to 125 slave devices (with repeaters), it simplifies network architecture without compromising on functionality, making it a trusted choice for both retrofitting legacy systems and building new, future-ready automation networks.

Label	Specification
Model Number	MVI56-PDPMV1
Brand	Allen-Bradley (ProSoft Technology for Rockwell Automation)
Type	PROFIBUS DP-V1 Master Communication Module for ControlLogix
Input Voltage	Backplane-powered: 5 VDC (800 mA) + 24 VDC (3 mA auxiliary)
Operating Temperature	-40°C to 85°C (storage); 0°C to 60°C (operation)
Communication Method	PROFIBUS DP-V0/V1 (RS-485, optical isolation), RJ45 configuration port
Mounting	Single-slot 1756 ，suitable for local/remote ControlLogix racks
Weight	Compact design (exact weight optimized for rack integration)
Certifications	Compliance with industrial standards (e.g., Class I, Division 2 for hazardous areas)
Dimensions	Standard ControlLogix module form factor for seamless rack installation
Protocols Supported	PROFIBUS DP-V1 (Class 1/Class 2 services), CIP Connect for Ethernet routing
Data Throughput	Up to 12 Mbps for high-speed cyclic data (1536 bytes I/O each direction)

The MVI56-PDPMV1 is built to thrive in the rugged conditions of industrial settings, where reliability and performance are paramount. Its high-speed data transfer rate of 12 Mbps ensures that real-time control signals and sensor data flow without delay, critical for applications like robotic assembly or precision manufacturing where split-second responses matter. Engineers appreciate its ability to handle both cyclic and acyclic communication, allowing it to manage routine control tasks alongside complex device configuration and diagnostic queries without compromising network stability.
