Description
Product Overview
The ABB 086329-004 is a high-performance industrial automation module designed for integration into control panels or Distributed Control Systems (DCS)/Programmable Logic Controllers (PLC) systems. This module serves as a vital link between different devices, networks, and control systems, enabling data communication and integration. With its state-of-the-art technology, the ABB 086329-004 ensures reliable and efficient operation in demanding industrial environments. Supporting a wide range of communication interfaces and protocols, it facilitates seamless connectivity with various devices and networks. The module is compact in size, making it suitable for space-constrained applications. Its robust construction ensures durability and longevity, reducing maintenance costs and downtime. The ABB 086329-004 is engineered to deliver exceptional performance and reliability, making it ideal for applications requiring high reliability, long-distance communication, and seamless integration into complex control systems.
Technical Specifications
Parameter Name |
Value |
Model Number |
086329-004 |
Manufacturer |
ABB |
Product Type |
Driver Board |
Dimensions (H x W x D) |
10 x 153 x 3 mm |
Weight |
0.26 kg |
Operating Voltage |
DC 24 V |
Operating Current |
≤ 100 mA |
Communication Interfaces |
RS-485, CANopen, Ethernet, Profibus DP, Modbus TCP/IP, Fiber Optic |
Power Consumption |
Less than 0.1W |
Operating Temperature Range |
-20°C to +70°C |
Storage Temperature Range |
-40°C to +85°C |
Protection Features |
Surge protection (600 W), Overcurrent protection (1.5 A), Lightning protection (4000 V) |
Mounting |
35 mm DIN rail or panel mounting |
Redundancy |
Dual-redundant power supplies and communication ports |
LED Indicators |
6 dual-color LEDs for status monitoring |

086329-004
Main Features and Advantages
The ABB 086329-004 module is equipped with a dual Profibus DP support, enabling simultaneous connection to two independent Profibus networks. This enhances system flexibility and redundancy. It also features an adaptive baud rate, supporting manual configuration of standard baud rates or automatic adaptation to the network speed. The module’s fiber optic communication provides immunity to electromagnetic interference (EMI) and supports distances up to 20 km, making it ideal for harsh industrial environments. It is designed to operate reliably in temperatures ranging from -20°C to +70°C, ensuring functionality in diverse climates. The ABB 086329-004 includes relay-based alarm outputs for signaling faults or system events to external monitoring systems. Its robust construction, made of aluminum housing with wave-pattern reinforcement, ensures durability and heat dissipation. The module meets industrial EMC standards for reliable operation in noisy electrical environments. With its high precision detection and real-time monitoring capabilities, it ensures the stability and reliability of electrical connections. The ABB 086329-004 is designed for easy integration into existing electrical systems or automation control equipment, supporting multiple communication interfaces.
Application Fields
The
ABB 086329-004 finds extensive application in various industrial sectors. In manufacturing automation, it integrates with PLCs and SCADA systems to control machinery, monitor production lines, and optimize processes. It is also used in process control industries such as oil and gas, chemicals, and water treatment for real-time monitoring and control of critical variables. In power distribution, it enables communication between intelligent electronic devices in substation automation systems. The module is applied in railway signaling, traffic management, and elevator control systems for reliable data exchange. In building automation, it facilitates the integration of HVAC, lighting, and security systems into a unified control network. Its ability to operate within a wide temperature range makes it suitable for a broad spectrum of industrial applications, from cold storage facilities to hot forging operations.

086329-004
Related Products
Here are some products related to the ABB 086329-004:
-
ABB ACS880-01-05A6-3: A drive controller that can be paired with the ABB 086329-004 for dynamic performance adjustments based on real-time data collected by the module.
-
ABB DSQC627: Integrates with the ABB 086329-004 to ensure seamless data communication across the automation network.
-
ABB CI940F Communication Interface Module: Works in conjunction with the ABB 086329-004 to provide comprehensive data analysis.
-
ABB PM573_ETH+DM-TOOL: Enhances signal processing capabilities when used with the ABB 086329-004, making the overall system more efficient.
-
ABB BRC3000A: Can be used alongside the ABB 086329-004 to achieve unparalleled levels of automation and control.
-
ABB KVC758A124: Another complementary model that works well with the
ABB 086329-004 to drive productivity and safety to new heights.

086329-004
Installation and Maintenance
Installation Preparation: Before installing the ABB 086329-004, ensure the installation site meets the specified environmental conditions regarding temperature, humidity, and electromagnetic compatibility. Prepare all necessary tools and thoroughly review the installation manual to familiarize yourself with the procedure and safety guidelines.
Maintenance Suggestions: Regular maintenance is crucial to ensure the longevity and optimal performance of the ABB 086329-004. This includes routine cleaning of the module to prevent dust accumulation, inspecting connections for tightness, and monitoring operational parameters. In case of any anomalies, prompt contact with ABB’s technical support is recommended.
Product Warranty
Our company provides a one-year quality warranty for the ABB 086329-004, covering hardware defects not resulting from external factors such as improper use or physical damage. During the warranty period, we are committed to replacing faulty units to minimize operational disruption. For discontinued models or urgent spare part requirements, our global supply chain ensures timely procurement and delivery, supporting the uninterrupted operation of your industrial systems.
