Description
Product Overview
The ABB 3BHE004573R0145 UFC760BE145 is a cutting-edge medium voltage drive interface module that belongs to ABB’s UNITOL 6000 series. It is specifically designed for high-precision motor control in industrial automation systems. With advanced control algorithms and high-efficiency power electronics, this module ensures stable system operation while significantly improving efficiency and reliability. As a crucial part of ABB’s high-performance medium voltage drive system, the ABB 3BHE004573R0145 UFC760BE145 supports voltage levels ranging from 3.3kV to 6.6kV and delivers ±0.1% speed regulation accuracy. It is ideal for critical torque control applications like nuclear power plants where high control precision and reliability are mandatory.Whatsapp:+86 17350880093
Technical Specifications
| Parameter Name | Value |
|---|---|
| Product Model | 3BHE004573R0145 UFC760BE145 |
| Manufacturer | ABB |
| Product Type | Medium Voltage Drive Interface Module |
| Rated Voltage | 3.3kV – 6.6kV (50/60Hz) |
| Operating Voltage | 230V AC |
| Output Frequency | 50Hz |
| Input Current | 2.0A |
| Control Accuracy | ±0.1% |
| Communication Protocols | MODBUS TCP/IP, PROFIBUS DP, Modbus TCP, IEC 61850 |
| Control Update Time | 250μs |
| Power Consumption | 24W @ 24V DC ±15% |
| Operating Temperature Range | -25°C to +55°C (derating above 40°C) |
| Shock Resistance | 5g @ 11ms (IEC 60068-2-27) |
| Dimensions | 482.6 x 132.5 x 405 mm (19″ rack) |
| Weight | 0.5kg |
| Protection Class | IP20 (front panel), IP00 (internal) |
| Certification | UL 508C, CE, cULus |
UFC760BE145
Main Features and Advantages
High-Precision Control: Utilizing advanced control algorithms, the ABB 3BHE004573R0145 UFC760BE145 achieves ±0.1% speed regulation accuracy, ensuring stable and precise motor operation. This makes it perfect for critical applications demanding exact control.
Wide Adaptability: The ABB 3BHE004573R0145 UFC760BE145 supports multiple voltage levels, making it suitable for various industrial scenarios. These include high-voltage inverters, frequency converters, wind energy, and photovoltaic systems. It offers extensive applicability and flexibility.
Efficient Power Management: By optimizing phase control and power quality, this module enhances system efficiency and reduces energy loss. Its integrated DC bus monitoring system allows real-time analysis of capacitor health, extending component lifespan.
Enhanced Connectivity: With dual redundant fiber optic communication channels and support for multiple fieldbus protocols and interface types, it ensures easy integration into existing control systems. This enables efficient data exchange between different devices.
Innovative Thermal Design: Featuring aluminum nitride ceramic substrate, it can handle continuous current up to 150A even at an ambient temperature of 85°C. This ensures stable operation in high-temperature and high-humidity environments.E-mail :sales@fyplc.cn
Application Fields
Power Systems: Used in high-voltage inverters and frequency converters to improve transmission efficiency and power quality. It ensures stable power system operation.
Industrial Automation: Ideal for high-power equipment in industries like metallurgy, mining, and cement. It enables precise motor control and speed regulation, boosting production efficiency and product quality.
Rail Transportation: Ensures stable traction system operation and reliability of high-voltage auxiliary power systems, guaranteeing smooth train operation.
New Energy Sector: Applied in wind energy and photovoltaic systems to optimize power output and enhance energy utilization, promoting new energy adoption and development.
UFC760BE145
Related Products
Here are some products related to ABB 3BHE004573R0145 UFC760BE145:
-
ABB 3BHE004573R0042 UFC760BE42: Also part of the UNITOL 6000 series, it has similar control and communication functions but is suitable for different voltage levels and application scenarios.
-
ABB ACS5000: ABB’s high-power medium voltage frequency converter series. When used with this interface module, it enables precise control of large motors, widely applied in industrial automation and energy sectors.
-
ABB PM866K01: Another control module from ABB, offering different control functions and interface types. It can be combined with this interface module to build complex control systems.
-
ABB AC800M: ABB’s advanced controller with high-performance processing and rich control functions. It can be used with this interface module to achieve precise control and optimization of complex industrial processes.Whatsapp:+86 17350880093
Installation and Maintenance
Installation Preparation: Before installing the ABB 3BHE004573R0145 UFC760BE145, ensure the installation environment meets the specified temperature, humidity, and electromagnetic interference requirements. Prepare the necessary installation tools and materials, carefully read the product manual, understand the installation steps and precautions, and ensure smooth installation.
Maintenance Suggestions: To ensure the long-term stable operation of the ABB 3BHE004573R0145 UFC760BE145, regular maintenance is required. This includes cleaning the module surface to ensure good heat dissipation; checking the tightness of terminal connections to prevent faults caused by poor contact; and regularly testing the module’s performance. If any issues arise during maintenance, promptly contact a professional technician for assistance.Whatsapp:+86 17350880093
UFC760BE145
Product Warranty
Our company offers a one-year quality warranty for the ABB 3BHE004573R0145 UFC760BE145, covering hardware failures not caused by humn factors. If the product exhibits abnormal performance or functional failure within the warranty period, we will provide replacement services. Additionally, for discontinued models or urgent requirements, we can leverage our global supply chain network to quickly meet customers’ procurement needs for scarce spare parts, ensuring the continuous and stable operation of industrial systems.
