ABB 3BHL000986P0006 – IGBT Power Module for Industrial Drive and Converter Repairs
ABB’s 3BHL000986P0006 is an IGBT power module typically used as a like‑for‑like spare in ABB drive and converter stacks. From my experience, maintenance teams reach for this part when a leg shows switching anomalies, excessive heat, or intermittent trips under load. One thing I appreciate is how it pairs well with ABB gate driver hardware, so you can restore clean switching behavior without rewriting control logic or reworking the cabinet layout.
Company’s Order Placement Process and Guarantees
- Warranty period: 365 days
- Delivery time: 1 week for in‑stock; no more than one month at the latest
- Payment method: 50% advance payment, full payment for delivery
- Express delivery methods: FedEx, UPS, DHL
- Process: Confirm model and quantity → Proforma Invoice → Advance payment → Functional testing and packing → Final payment → Express shipment with tracking
Key Features
- OEM IGBT module – Suited for ABB drive/converter positions where a failed leg or thermally stressed device needs a like‑for‑like swap.
- High‑efficiency switching – Helps keep converter losses predictable and thermal margins healthy when matched to the correct gate driver.
- Mechanical baseplate design – Bolt‑down mounting for solid thermal coupling to the stack heatsink.
- Service‑friendly replacement – In most cases, field cabling and busbar geometry remain unchanged during a planned module exchange.
- Quality‑screened – We can perform insulation, gate, and basic curve checks so you receive a device that’s ready to install.
Technical Specifications
| Brand / Model | ABB – 3BHL000986P0006 (IGBT Power Module) |
| HS Code | 854129 (Power transistors – IGBT modules) |
| Power Requirements | Gate drive and DC link are provided by the converter; no independent LV supply on the module itself |
| Dimensions & Weight | Bolt‑down baseplate module; footprint and mass per ABB drawing for 3BHL000986P0006 |
| Operating Temperature | Module case/junction limits per ABB datasheet; install in a ventilated cabinet with rated cooling |
| Signal Input/Output Types | Power terminals (C/E), gate/emitter control pins; many builds include NTC temperature sense |
| Communication Interfaces | None (semiconductor device) |
| Installation Method | Bolt to a flat heatsink with thermal interface; torque to spec; connect to busbars and driver per OEM drawing |
Application Fields
You’ll typically see this module in ABB industrial drives and converters where efficiency and uptime matter:
- ABB low‑ and medium‑voltage drive stacks handling pump, fan, and compressor duty
- Process industries: metals, mining, cement, chemicals with demanding cycles
- Lifecycle extensions during stack refurbishments and planned outages
- Spares programs to keep N‑1 coverage on critical production lines
Advantages & Value
- Reliability: A fresh IGBT often tightens switching margins and reduces nuisance trips linked to heat or partial failures.
- Compatibility: Designed for ABB stacks—keeps existing drivers, snubbers, and busbar geometry intact in most cases.
- Cost & downtime: Like‑for‑like replacement is usually faster and cheaper than re‑engineering an entire phase leg.
- Testing support: We can provide insulation (HiPot), gate threshold, and basic static checks before shipment.
“Replaced a suspect device with 3BHL000986P0006. Heat signature dropped, switching waveforms cleaned up, and the drive has run quietly through two production runs.” — Maintenance engineer, cement plant MV drive room
Installation & Maintenance
- Heatsink prep: Ensure a clean, flat surface; apply the recommended thermal compound; torque mounting hardware evenly in a cross pattern.
- Driver matching: Verify gate resistor values and driver compatibility; keep gate/emitter leads short and symmetrical.
- Electrical safety: LOTO; allow DC link to fully discharge; ESD precautions when handling the module and driver cables.
- Busbar layout: Maintain original creepage/clearance; re‑torque power terminals after first thermal cycle if required by procedure.
- Commissioning: Check temperature sensor reading (if present), confirm snubber health, and scope a low‑load start for clean edges.
- Routine care: Keep filters/ducts clean, inspect for hot spots via thermal scan, and review trip logs for early warnings.
Quality & Certifications
- Manufacturing quality: Produced under ISO 9001 systems (typical for ABB power semiconductors).
- Compliance: Intended for installation inside CE/UL compliant converter systems; RoHS status depends on production year.
- Warranty: 365‑day warranty from shipment date.
If you can share the drive type, stack position, and the current driver/gate resistor values, we’ll double‑check interchangeability for 3BHL000986P0006 and provide a brief pre‑shipment test report.
