ABB 560BIR01 – Binary Input Interface Module

Product Overview

The ABB 560BIR01 is a binary input interface module designed for reliable signal acquisition in industrial automation and distributed control systems. It is commonly deployed in ABB control platforms to monitor digital status signals from field devices such as limit switches, protection relays, push buttons, and auxiliary contacts.

This module converts discrete field signals into digital data that can be processed by the control system for monitoring, protection logic, and automated process control. The ABB 560BIR01 provides stable signal conditioning and high-speed response, ensuring accurate detection of equipment states and process events.

With its industrial-grade design and compatibility with ABB automation architectures, the module contributes to enhanced system visibility, operational safety, and reliable communication between field instrumentation and control processors in complex industrial environments.

Technical Specifications

• Product Model: 560BIR01

• Brand: ABB

• Warranty: One Year

• Input Voltage: 24 VDC digital signal input

• Operating Temperature: -20°C to +60°C

• Storage Temperature: -40°C to +85°C

• Response Time: ≤5 ms signal detection

• Protection Class: IP20

• Accuracy Class: Industrial Digital Signal Grade

• Output Frequency: Not applicable (digital input module)

• Rated Current Range: Typical digital input range 5–15 mA per channel

• Communication Interface: System Backplane Interface

• Supported Protocols: Internal control bus communication (ABB automation systems)

• Overload Capacity: Protected against transient voltage spikes and industrial electrical noise

• Dimensions: Approx. 120 × 90 × 40 mm

•

Main Features and Benefits

Reliable Digital Signal Acquisition:
The module captures discrete signals from field devices with high reliability, ensuring accurate monitoring of equipment status and process conditions.

Fast Response Time:
With rapid signal detection capability, the module allows the control system to react quickly to operational events, improving safety and process stability.

Robust Industrial Design:
The ABB 560BIR01 is designed to operate in harsh industrial environments, offering resistance to electrical interference and temperature variations.

Seamless System Integration:
Engineered for ABB automation platforms, the module integrates directly with distributed control systems and PLC architectures, simplifying installation and configuration.

Application Scenarios

Power Generation Plants:
Used to monitor breaker status, protection relay signals, and turbine auxiliary system conditions in power plant automation systems.

Oil and Gas Facilities:
Captures digital signals from field instrumentation, safety switches, and emergency shutdown systems to support process safety monitoring.

Industrial Manufacturing:
Deployed in production lines to track machine status, limit switches, and operator control inputs within automated manufacturing systems.
