Description
ABB ACS100-PAN – Operator Panel for ACS100 Variable Speed Drives
The ABB ACS100-PAN is the detachable operator/control panel designed for the legacy ABB ACS100 series drives. From my experience, it’s the fastest way to commission or tweak an ACS100 on the shop floor—navigate parameters, start/stop locally (if permitted), and pull fault codes without opening tools. You might notice that it’s powered directly from the drive, so there’s no external PSU or extra wiring hassle. For many maintenance teams keeping ACS100 installations running, this panel is a simple, reliable spare that minimizes downtime.
Order Placement Process & Guarantees
- Warranty: 365 days
- Delivery: 1 week if in stock; no more than one month at the latest
- Payment: 50% advance payment; full payment prior to delivery
- Express options: FedEx, UPS, DHL
Key Features
- Dedicated interface for ABB ACS100 drives: Plug-on panel designed to match the ACS100 series without adapters.
- Drive-powered convenience: Receives low-voltage power from the drive; typically no external power supply required.
- Quick parameter access: Navigate, edit, and copy key parameters for commissioning and service tasks.
- Local control (when enabled): Start/stop and speed adjustments for functional testing and troubleshooting.
- Remote-door mounting option: Can be extended to the cabinet door with a suitable panel cable for safer operator access.
- Straightforward diagnostics: View status and fault information to shorten fault-finding time.
Technical Specifications
| Brand / Model | ABB / ACS100-PAN |
| Product Type | Detachable operator panel for ABB ACS100 variable frequency drives |
| HS Code | 8504.90 (Parts of static converters) |
| Power Requirements | Supplied by the ACS100 drive via low-voltage panel bus; no external power needed |
| Operating Temperature | 0 to +50 °C (typical for control panels; install in a ventilated enclosure) |
| Signal Input/Output Types | N/A (human-machine interface; no field I/O) |
| Communication Interfaces | Proprietary ABB panel bus via the drive’s panel connector; optional remote cable for door mounting |
| Installation Method | Direct plug-on to ACS100 front; or remote door-mount with cable and bracket (where used) |
| Dimensions & Weight | Compact handheld-sized panel; lightweight (typically < 0.2 kg) |
Application Fields
The ACS100 series often shows up in light industrial and OEM machinery. This panel keeps those systems serviceable:
- HVAC fans and small pumps needing quick parameter tweaks during balancing or retrofits
- Conveyors, feeders, and packaging lines where operators fine-tune speed during changeovers
- Mixers, agitators, and simple process equipment in food & beverage or chemicals
- General-purpose machine tools and material handling rigs that still run on ACS100 drives
Advantages & Value
- Reliability for legacy systems: Keeps existing ACS100 installations operational; no learning curve for technicians.
- Compatibility: Purpose-built for ACS100—no pinout guessing or third-party adapters.
- Cost control: Restores on-site setpoint/diagnostics without replacing the entire drive.
- Reduced downtime: Quick fault access and parameter edits speed up maintenance windows.
- Supportable lifecycle: From my experience, stocking a spare panel is one of the simplest mitigations for older VFD fleets.
Installation & Maintenance
- Cabinet and mounting: For door-mounting, use a suitable cutout and bracket; keep the panel within the operator’s ergonomic reach and away from moisture.
- Wiring and EMC: If remotely installed, route the panel cable separately from high-power conductors; use the recommended cable to avoid noise issues.
- Ventilation: Maintain enclosure temperature within 0…50 °C; avoid direct sunlight and condensation.
- Safety: Apply ESD precautions when attaching/detaching the panel; switch the drive to a safe state before changes.
- Routine care: Wipe dust from the keys and display; check cable/connectors for oxidation; back up key parameters at each service interval.
Quality & Certifications
- Manufacturer-grade quality for ABB ACS100 ecosystem
- Compliance typically includes CE; many installations also reference UL and RoHS for panel accessories
- Warranty: 365 days
Supporting Components (for a complete setup)
- ABB ACS100 frequency converter (various ratings): The host drive series that the ACS100-PAN interfaces with.
- Remote panel cable: Panel-bus extension cable for door mounting; length selected based on cabinet layout.
- Door-mounting frame/bracket: For a clean front-panel installation and improved ingress protection through the cabinet door hardware.
A quick note from a recent maintenance team we supported: swapping a damaged panel with a spare ACS100-PAN got a small conveyor line back in under 20 minutes—no parameter rework, no surprises. That’s typically the kind of low-effort win this accessory brings to older but dependable ACS100 sites.
