ABB CI522AK04 (3BSE018451R1) – Compact Serial Communication Interface for integrating third‑party devices into ABB S800 I/O/AC 800M systems

The ABB CI522AK04 seems to be part of the CI522A family of communication modules used with S800 I/O. In many cases it’s applied where an AC 800M or Advant/ABB DCS needs a reliable serial link to drives, power meters, analyzers, or other skid packages. From my experience, it’s a practical way to bring Modbus‑style serial data (RTU/ASCII over RS‑485/RS‑232) into your controller without adding a bulky gateway. You might notice that the single‑width S800 form factor helps keep cabinets tidy, and it typically supports the familiar S800 terminal bases for quick swap‑outs.

Order Placement Process and Guarantees

• Warranty: 365 days
• Delivery: 1 week for in‑stock items; no more than one month at the latest
• Payment: 50% advance payment, full payment before delivery
• Express options: FedEx, UPS, DHL

Key Features

• Serial connectivity for field devices – Typically supports Modbus RTU/ASCII via RS‑485/RS‑232, ideal for drives, meters, and analyzers.
• S800 I/O form factor – Single‑width module that mounts on TU8xx terminal bases for fast installation and replacement.
• Engineering tool alignment – Works with ABB engineering environments (e.g., Control Builder M or Freelance tools depending on the controller), which helps cut configuration time.
• Status and diagnostics – Front LEDs and standard diagnostics make commissioning quicker and troubleshooting more straightforward.
• Industrial temperature range – Designed for typical S800 I/O ambient conditions used in process plants and utilities.
• Clean cabinet integration – You can route shielded twisted pair to the TU base, which keeps wiring simple and serviceable.

Technical Specifications

Application Fields

Plants that need to pull serial data into ABB DCS/PLC platforms benefit the most. Typical examples:

• Power & utilities – linking power quality meters and protective relays using Modbus RTU.
• Water & wastewater – integrating pump VFDs and flow totalizers on RS‑485 multi‑drop loops.
• Oil, gas & chemicals – reading gas analyzers, weigh scales, and package skids with simple serial protocols.
• Food & beverage – connecting OEM skid controls and temperature controllers during line upgrades.
• Marine & metals – bridging legacy serial instruments into modern ABB control networks.

Advantages & Value

• Lifecycle fit – Keeping everything in the S800 ecosystem usually reduces spare stock and training overhead.
• Shorter commissioning – Consistent diagnostics and engineering workflow help teams finish loops faster.
• Cabinet efficiency – Single‑width footprint saves rail space versus external gateways.
• Reliable serial backbone – Proper termination and shielding on the TU base typically delivers stable multi‑drop RS‑485 links.
• Serviceability – Technicians can replace the module on the TU base without disturbing field wiring.

Installation & Maintenance

• Cabinet & mounting – Install on a compatible S800 TU base (e.g., TU810/TU812/TU842) on a grounded DIN rail with adequate ventilation. Avoid heat sources and high‑EMI zones.
• Wiring – Use shielded twisted pair for RS‑485; ground the shield at one end. Keep serial and power wiring separated from high‑voltage runs.
• Termination & bias – Apply 120 Ω termination at the ends of the RS‑485 trunk and ensure proper biasing as per ABB recommendations on the TU base.
• Configuration – Set baud rate, parity, and addressing consistently with the device list. In most cases, Modbus mapping is straightforward once the register map is verified.
• Routine maintenance – Inspect terminal tightness quarterly, check error counters in diagnostics, and keep firmware/tooling aligned with your plant standard.
• Safety – De‑energize the segment before wiring changes; ESD precautions apply when handling the module.

Quality & Certifications

• CE compliant; typically UL/cUL and RoHS for S800‑series modules.
• Manufactured to ABB’s process control hardware standards for long‑term availability.
• Warranty: 365 days from shipment.

Recommended Supporting Components

• TU810 / TU812 / TU814 / TU842 Terminal Bases – Provide the field wiring interface and ModuleBus connection for CI‑series S800 modules.
• TB805 ModuleBus Connectors – For daisy‑chaining S800 modules with proper bus integrity.
• Shielded RS‑485 cable – 120 Ω characteristic impedance for reliable multi‑drop communication.
• DIN‑rail power conditioner (24 V DC) – Helps maintain clean power to the I/O islands, especially on long runs.
