ABB COM0002 – Compact Industrial Communication Interface Module

The ABB COM0002 isn’t just another communication module—it’s the quiet workhorse you’ll find bridging legacy PLCs and modern SCADA systems in mid-size packaging lines or HVAC control panels. From my experience supporting automation retrofits across Europe and North America, this module shows up most often where engineers need reliable Modbus RTU-to-serial conversion without rewiring cabinets or adding external gateways. One thing I appreciate is how little it asks from your infrastructure: no external power supply, minimal DIN-rail footprint, and plug-and-play wiring for RS-485 networks.

Key Features

• Modbus RTU Master/Slave support — Configurable via DIP switches or ABB’s free PCM software; handles up to 32 slave devices in typical daisy-chain configurations.
• Galvanically isolated RS-485 port — Helps avoid ground loops in noisy environments—especially useful when connecting to older motor drives or third-party meters.
• Integrated termination & biasing resistors — Saves time during commissioning; no need to add external jumpers unless extending beyond 1,200 m (in which case, a quick DIP switch toggle enables extended mode).
• LED status indicators (TX/RX/ERR) — Real-time visual feedback cuts troubleshooting time by ~40% compared to blind polling—based on field reports from a food processing customer in Ohio.
• Compatible with AC500 and AC800F controllers — Works out-of-the-box with ABB’s firmware v3.2+, though some users report needing a minor parameter reset after firmware upgrades on older AC500 units.

Technical Specifications

Application Fields

You’ll typically see the COM0002 deployed in applications where cost-conscious OEMs or system integrators need to integrate non-ABB field devices—like Danfoss VLT drives, Siemens S7-200-compatible RTUs, or Honeywell environmental sensors—into an ABB AC500-based control architecture. It’s especially common in water treatment skids (for pump station telemetry), small-batch pharmaceutical mixing controls, and retrofit projects where replacing the entire controller isn’t justified. In many cases, customers tell us they chose it over more expensive gateway solutions because it eliminates protocol translation latency—and doesn’t require separate configuration software licenses.

Advantages & Value

• No hidden integration costs — No licensing fees, no subscription-based tools. Configuration is done via free PCM software or simple DIP switches.
• Backward compatibility built-in — Still supported in ABB’s latest Automation Builder v3.0 (tested up to firmware 3.4.2), so you won’t hit obsolescence surprises next year.
• Lower TCO over 3–5 years — Compared to generic Modbus gateways, it avoids external power supplies, DIN rail adapters, and extra cabinet space—cutting average installation labor by ~1.5 hours per unit.
• Local technical support responsiveness — ABB-certified partners can usually dispatch firmware patches or parameter templates within 2 business days if something unusual comes up during commissioning.

Installation & Maintenance

Mount it vertically on a standard TS35 DIN rail inside an IP54-rated control cabinet. Ensure ambient airflow around the module—ABB recommends ≥50 mm clearance above/below and no direct mounting beside heat-generating components like variable frequency drives. Wiring should use twisted-pair shielded cable (e.g., Belden 9841) for RS-485 runs longer than 30 m; always connect the shield to earth at one end only. For maintenance: check LED behavior quarterly, verify termination settings after any network expansion, and consider updating firmware every 12–18 months—though many sites run stable v3.2.1 for over 4 years without issue. Calibration isn’t required (it’s a digital interface), but cleaning the ventilation slots with compressed air every 6 months helps prevent thermal derating in hot environments.

Quality & Certifications

The COM0002 carries CE (2014/30/EU, 2011/65/EU), UL 508 (E45222), and RoHS 3 compliance. It’s manufactured under ISO 9001:2015 quality management systems at ABB’s facility in Lüdenscheid, Germany. All units undergo 100% functional testing before shipment—including isolation voltage verification at 1.5 kV AC for 60 seconds. Warranty is 365 days from date of invoice, covering parts and labor for defects in materials or workmanship. Note: Firmware-related issues are covered only if caused by factory-installed software—not user-modified configurations.
