ABB FI810F (3BDH000030R1) – PROFIBUS DP-V1 Fieldbus Interface for Freelance AC 800F
The ABB FI810F is a PROFIBUS DP-V1 fieldbus interface module designed for the Freelance AC 800F platform. From my experience, it’s the go-to choice when you need a stable DP master that plays nicely with mixed-vendor devices and keeps commissioning time predictable. You might notice that diagnostics are straightforward—status LEDs and Control Builder Freelance make it easy to pinpoint wiring or GSD issues without hunting through multiple tools.
Our Order Placement Process and Guarantees
- Warranty period: 365 days
- Delivery time: 1 week for in-stock items; no more than one month at the latest
- Payment: 50% advance payment; full payment before delivery
- Express delivery: FedEx, UPS, DHL
Key Features
- PROFIBUS DP-V1 master – Handles Class 1 master tasks for cyclic I/O; acyclic parameterization is supported for smart devices.
- Auto-baud up to 12 Mbit/s – Typically locks onto existing bus speed, which simplifies brownfield upgrades.
- Robust RS-485 physical layer – Shielded, twisted-pair with standard 9-pin D-Sub connection; galvanic isolation between bus and system.
- Tight integration with Freelance – Engineering via Control Builder Freelance using standard GSD files; smooth device mapping and diagnostics.
- Segment scalability – Standard RS-485 segment rules apply (up to 32 nodes per segment without repeaters; more with properly powered repeaters).
- Status LEDs and clear diagnostics – Speeds up troubleshooting for cabling, termination, or device timeouts.
- Compact DIN-rail design – Fits alongside AC 800F modules; wiring and front access are straightforward.
Technical Specifications
| Brand / Model | ABB FI810F (Part No. 3BDH000030R1) |
| Function | PROFIBUS DP-V1 fieldbus interface (Class 1 Master) for Freelance AC 800F |
| HS Code | 8538.90 (Parts for switchgear/control apparatus) |
| Power Requirements | 24 V DC (typical 19.2–30 V DC), consumption typically < 5 W |
| Communication Interfaces | PROFIBUS DP (RS-485), 9-pin D-Sub; 9.6 kbps to 12 Mbps, DP-V0/DP-V1 |
| Signal I/O Types | Fieldbus interface only (no direct analog/digital channels) |
| Dimensions & Weight | Approx. 130 × 71 × 60 mm; ~0.25 kg |
| Operating Temperature | 0 to +55 °C (storage typically −25 to +70 °C) |
| Installation Method | DIN-rail mounting on AC 800F module carrier; front-access connectors and status LEDs |
| Isolation | Galvanic isolation between PROFIBUS and system side |
Application Fields
The FI810F typically sits at the heart of brownfield and greenfield process automation projects where PROFIBUS remains a solid choice:
- Chemicals and specialty chemicals – Connecting DP drives, weigh scales, and remote I/O in hazardous-adjacent areas (with suitable field devices).
- Water & wastewater – Integrating remote MCCs, valve islands, and instrumentation across long runs using RS-485.
- Power generation – Turbine balance-of-plant skids, utility systems, and package equipment with standard GSD catalogs.
- Oil & gas (midstream/downstream) – Compressor skids, burner management interfaces, and flow computers with DP-V1 capability.
- Food & beverage – Packaging lines, servo drives, and I/O slices on conveyor cells.
A commissioning engineer told us that switching a mixed-vendor DP segment onto FI810F “took one afternoon, including address audit and a few terminator flips.” That seems to be the norm when the physical layer is clean and the GSD set is prepared.
Advantages & Value
- Reliability – Stable DP master behavior with clear diagnostics; fewer nuisance timeouts when cabling and termination follow spec.
- Compatibility – Works with a wide range of DP slaves using standard GSDs; DP-V1 acyclic access helps with parameter-heavy devices.
- Lifecycle-friendly – A practical drop-in when maintaining existing PROFIBUS assets without forcing a protocol migration.
- Cost savings – Uses existing DP wiring and connectors; typically avoids re-pulling cable during controller modernization.
- Technical support – Well-documented within the Freelance environment; predictable engineering workflow.
Installation & Maintenance
- Cabinet & mounting – Mount on DIN rail with the proper AC 800F carrier. Provide ventilation; keep ambient within 0…55 °C.
- Power – 24 V DC supply with appropriate grounding. Keep fieldbus cable shielding bonded at cabinet entry.
- Wiring – Use PROFIBUS cable Type A. Maintain correct D-Sub pinout. Enable termination only at both physical ends of each segment.
- Segment design – Up to 32 nodes per RS-485 segment without repeaters; more with powered repeaters. Observe length vs. speed rules (e.g., 100 m at 12 Mbps; longer at lower speeds).
- EMC practices – Separate signal and power wiring, use shield clamps, and avoid star topologies on DP.
- Maintenance – Periodically inspect connectors and terminators; clean dust; verify device addresses. Firmware updates can be scheduled during planned downtime.
- Spare strategy – Keeping one FI810F on the shelf typically shortens recovery time; hot swap is possible in many cases, but follow ABB procedures.
Quality & Certifications
- CE conformity; RoHS compliant
- UL/cUL Recognized (typical for ABB control modules)
- Manufacturing quality aligned with ISO 9001 processes
- Manufacturer warranty practices typically apply; we provide a 365-day warranty on supply
Common Accessories and Complementary Items
- PROFIBUS DP D-Sub connectors with integrated terminators (right-angle or straight)
- PROFIBUS Type A shielded cable; DIN-rail shield clamps and grounding kits
- PROFIBUS repeaters/isolators for long segments or heavy node counts
- Labeling sets and ferrules for cleaner commissioning records
One thing I appreciate is how consistent the FI810F behaves across device families—drives, ET200-class I/O, valve islands. In many cases, if the GSD is clean and the bus is properly terminated, you get a stable scan without tweaking obscure settings.
