ABB PPD113B03-26-100110 (3BHE023584R2634) – Control Board for AC 800PEC Drive and High-Performance Control Systems

The ABB PPD113B03-26-100110, part number 3BHE023584R2634, is a plug-in control board designed for the AC 800PEC platform. From my experience, this module is typically used in demanding applications like high-power drives, winders, and turbine/excitation systems where deterministic control and fast I/O handling are essential. You might notice that teams choose it as a direct, form-fit-function replacement to restore a downed AC 800PEC-based system in minutes rather than days.

Our Order Placement Process and Guarantees

• Warranty: 365 days
• Delivery Time: 1 week if in stock; no more than one month at the latest
• Payment: 50% advance payment, full payment before delivery
• Express: FedEx, UPS, DHL

Key Features

• AC 800PEC Compatibility – Designed to integrate with ABB’s AC 800PEC controller platform, maintaining OEM behavior and timing.
• Backplane-Powered 24 VDC – Draws its supply via the AC 800PEC backplane, simplifying wiring and keeping panels tidy.
• High-Speed Control Path – Suited to fast control loops common in drives and excitation; helps minimize downtime when used as a replacement board.
• Robust Industrial Build – Conformal-coated PCB and industrial-grade components are commonly used to improve reliability in harsh cabinets.
• Service-Friendly – Plug-in form factor with front-edge connectors typically allows quick swap and straightforward commissioning.
• Traceable Part Numbering – Clear ABB identifiers (PPD113B03-26-100110 / 3BHE023584R2634) help with spares management and lifecycle tracking.

Technical Specifications

Application Fields

The PPD113B03-26-100110 is commonly found in:

• Medium/high-power drives and converters (ACS/PEC-based systems)
• Paper machines and winders where fast loop control matters
• Metals and rolling mills, including coordinated multi-drive lines
• Excitation and turbine control platforms using AC 800PEC
• Marine and traction applications that require high reliability

A maintenance lead at a steel plant told us they keep two of these on the shelf; when a PEC rack flags a board fault, a 10-minute swap typically gets production back before quality is impacted.

Advantages & Value

• Reliability – OEM-spec board for the AC 800PEC environment; robust under electrical noise and cabinet heat.
• Compatibility – Form, fit, and function matched to the original part number for straightforward replacement.
• Downtime Savings – In many cases, a swap-and-run approach beats re-engineering or retrofits by a wide margin.
• Procurement Confidence – Traceable part ID and serials; clear HS Code for customs; pre-shipment testing available on request.
• Support – Practical guidance on installation and firmware alignment to reduce commissioning risk.

Installation & Maintenance

• Environment – Install in a clean, ventilated control cabinet. Keep ambient within 0…55 °C and avoid condensation.
• Wiring & Backplane – Power down the rack fully. Inspect backplane connectors for dust/oxidation and seat the board evenly; secure with the captive screws.
• ESD Safety – Wear a grounding strap and handle by edges only; avoid touching components and pins.
• Firmware/Configuration – Align board firmware and configuration with the existing AC 800PEC project. Back up the application before any swap.
• Routine Care – Periodically clean cabinet filters; blow off dust with dry, oil-free air; check connector torque and signs of heat discoloration.
• Preventive Spares – Keeping one tested spare on-site typically shortens MTTR from hours to minutes.

Quality & Certifications

• CE compliant design; RoHS-compliant build in most variants
• UL recognition for relevant assemblies/components (typical for ABB control boards)
• Manufactured within ISO 9001 quality systems (ABB standard practice)
• Supplier warranty: 365 days from delivery

Need help confirming fit with your AC 800PEC setup or matching firmware? Share your current controller revision and rack configuration, and we’ll cross-check against PPD113B03-26-100110 (3BHE023584R2634) to minimize any integration surprises.
