Product Title

ABB SCC‑C 23070‑0‑102321100000 ‑ Sample Gas Cooler / Conditioner Unit

Product Overview

The ABB SCC‑C 23070‑0‑102321100000 is a sample gas cooler and conditioner module engineered for continuous gas analysis systems in industrial process and environmental monitoring applications. Part of ABB’s SCC‑C family of sample handling equipment, this unit is used to reduce moisture and condensation in gas samples before they enter analytical instruments, ensuring accurate readings and reliable performance from gas analyzers.

Designed for compact mounting and integration with sample feed units such as the ABB SCC‑F series, the ABB SCC‑C 23070‑0‑102321100000 supports one or two gas paths with configurable heat exchanger and condensate handling options. Its robust construction, corrosion‑resistant components, and controlled dew point output make it suitable for demanding industrial environments including petrochemical plants, emissions monitoring systems, and process control analyzers.

Technical Specifications

• Product Model: SCC‑C 23070‑0‑102321100000

• Brand: ABB

• Warranty: One Year

• Input Voltage: Local power supply (module dependent)

• Operating Temperature: Up to ~50 °C ambient

• Storage Temperature: Typical industrial storage range

• Response Time: Continuous conditioning operation

• Protection Class: IP20 per EN 60529

• Accuracy Class: Sample conditioning instrumentation grade

• Output Frequency: N/A (conditioning output)

• Rated Current Range: N/A (sample conditioning device)

• Communication Interface: Optional controller integration port

• Supported Protocols: System‑specific analyzer interface

• Overload Capacity: Designed for continuous sample conditioning use

• Dimensions: Compact ½ 19″ rack or surface mount housing

• Gas Throughput: Configurable up to 2 × ~125 l/h or 1 × ~250 l/h (depends on path configuration)

Main Features and Benefits

Effective Moisture Control:
Reduces sample gas dew point before analysis to prevent condensation and protect analyzers from water vapor interference.

Multi‑Path Conditioning Options:
Supports configurations with one or two independent gas paths, improving flexibility for various process analysis requirements.

Modular and Accessible Design:
Compact surface‑mountable module with accessible components simplifies installation, maintenance, and integration with gas feed units.

Corrosion‑Resistant Construction:
Heat exchanger materials (e.g., glass, PVDF, stainless steel) and corrosion‑resistant gas lines ensure long‑term reliability in harsh sample environments.

Application Scenarios

Emission Monitoring Systems:
Prepares process gas samples for continuous analyzer systems used in environmental compliance and stack monitoring.

Process Control Gas Analysis:
Installed ahead of analyzers in chemical and petrochemical processes where accurate gas composition measurement is critical.

Laboratory and Field Analyzers:
Used in industrial labs or field analyzers requiring stable and dry gas samples for precise measurements.

Frequently Asked Questions (FAQ)

Q: What does ABB SCC‑C 23070‑0‑102321100000 do?
A: The ABB SCC‑C 23070‑0‑102321100000 is a sample gas cooler/conditioner that reduces dew point and removes condensate from humid gas samples, improving measurement accuracy and protecting analytical instruments.

Q: Can this unit integrate with other ABB sample handling components?
A: Yes. It is typically paired with ABB sample feed units such as the SCC‑F and integrated into analyzer systems using communication interfaces for status and alarm reporting
