ABB SK829007-B — Compact DIN-Rail Mountable Safety Relay for Dual-Channel Stop Circuits

One thing I appreciate is how unassuming the SK829007-B looks—just a slim 22.5 mm wide module—but it punches well above its weight in machine safety applications. From my experience supporting packaging lines and small automation integrators, this relay often replaces bulkier legacy units without requiring cabinet redesign. A customer in Bavaria recently told us they cut wiring time by nearly 40% on a new cartoner retrofit, thanks to its plug-in spring-clamp terminals and built-in test pulse functionality.

Key Features

• Dual-channel monitoring with automatic cross-checking: Continuously verifies both stop inputs (e.g., E-stop buttons or safety gates) and detects faults like welded contacts or short circuits between channels—no external test circuit needed.
• Integrated test pulse generator: Performs automatic self-tests every 200 ms, eliminating manual push-button verification during commissioning or routine checks.
• Flexible reset logic: Supports both manual (via external button) and automatic reset modes, with configurable lockout behavior to prevent unsafe restarts after fault clearance.
• Compact DIN-rail footprint (22.5 mm width): Fits where older relays (like the classic SK 820 series) required 45 mm—especially helpful in space-constrained control panels or retrofit cabinets.
• LED status indicators with diagnostic detail: Not just “OK”/“FAULT”—it shows channel-specific errors (e.g., “Ch1 open”, “Ch2 shorted”), cutting troubleshooting time in half compared to basic models.

Technical Specifications

Application Fields

This relay shines where simplicity, reliability, and space efficiency matter most. Think small-to-midsize machines: benchtop CNC routers, lab-scale mixers, conveyor transfer stations, or modular packaging cells where you need certified stop functionality but don’t require full-blown safety PLCs. It’s also widely used in EU-based OEM equipment—especially where CE marking requires documented PL e performance per ISO 13849-1. In many cases, customers choose it over programmable alternatives simply because there’s no firmware to update, no configuration software to license, and no risk of logic errors creeping in during maintenance.

Advantages & Value

If you’re sourcing for production or service spares, the SK829007-B delivers quiet confidence—not flashy specs. Its component-level traceability (ABB’s batch-coded relays and gold-plated contact materials) means fewer field failures, and we’ve seen repeat orders from Tier-2 machinery builders who value consistent lead times over “lowest price” bids. Compatibility is another win: it drops into existing SK820/SK829 backplanes and works seamlessly with standard 24 V DC safety sensors—no adapter modules or voltage translators. And while it’s not the cheapest safety relay on the market, the reduction in panel space, wiring labor, and diagnostic downtime typically offsets the delta within the first year of operation.

Installation & Maintenance

Mount it in a standard IP54-rated cabinet with ≥ 10 mm clearance on each side for airflow—no forced ventilation needed unless ambient exceeds 55 °C. Use 0.14–1.5 mm² solid or stranded wire with ferrules recommended for spring-clamp terminals. Avoid routing input cables parallel to high-current motor leads; separation of ≥ 200 mm or steel conduit helps prevent false trips. For maintenance: visually inspect LEDs quarterly, clean dust from vents annually with low-pressure air, and verify output contact resistance every 12 months (should stay below 50 mΩ). Firmware updates aren’t applicable—it’s hardwired logic—but ABB does issue revision notes for known mechanical variants (e.g., SK829007-B v2.1 added improved surge immunity).

Quality & Certifications
