ABB SNAT604-5761861-2B Configurable Card Module Three-phase Trip
Brand model: ABB
Product Name: SNAT604-5761861-2B
Warranty: 1 year
Size: 145 mm x 145 mm x 100 mm (5.7 in x 5.7 in x 3.9 in)
Weight: 0.5kg
Status: New/Used
Categories: ABB
Need help?
Email: sales@fyplc.cn
Tel/WhatsApp: +86 173 5088 0093
Description
ABB SNAT604-5761861-2B Configurable Card Module Three-phase Trip
As part of the Advant Master 31 ecosystem, the SNAT604-5761861-2B excels in environments requiring high-speed data transfer (up to 1 Mbps) and robust connectivity. Its rugged construction, compliant with industrial standards, ensures reliable performance in harsh conditions, including temperature ranges from -20°C to +55°C. By reducing latency and enhancing interoperability, the module streamlines system integration, making it ideal for retrofitting legacy systems or deploying next-generation automation setups. Its plug-and-play compatibility with ABB’s engineering tools further minimizes commissioning time, delivering cost-effective scalability.
| Parameter | Value |
|---|---|
| Product Model | ABB SNAT604-5761861-2B |
| Manufacturer | ABB |
| Product Type | Communication Network Adapter Module (Advant Master 31 DCS) |
| Power Input | 24–250 V DC/AC (wide-range compatibility) |
| Communication Protocols | Industrial Ethernet, TCP/IP, UDP, Modbus RTU |
| Data Transfer Rate | Up to 1 Mbps |
| Operating Temperature | -20°C to +55°C (-4°F to 131°F) |
| Storage Temperature | -40°C to +85°C (-40°F to 185°F) |
| Dimensions (WxHxD) | 145 mm x 145 mm x 100 mm (5.7 in x 5.7 in x 3.9 in) |
| Mounting | DIN rail or panel-mountable (compatible with Advant Master 31 racks) |
| Protection Class | IP40 (front panel); IP20 (rear terminals) |
| Redundancy Support | Optional dual-module configuration for mission-critical applications |
| MTBF (Mean Time Between Failures) | >80,000 hours (per ABB reliability benchmarks) |
Key Features and Benefits
The ABB SNAT604-5761861-2B stands out for its protocol flexibility, supporting both standard industrial protocols (e.g., Modbus) and ABB’s proprietary interfaces. This versatility allows it to connect diverse devices—from legacy sensors to modern smart actuators—without requiring additional converters, reducing hardware complexity. Its high-speed data transfer ensures real-time responsiveness, critical for applications like conveyor belt synchronization in automotive plants or turbine control in power generation.
The ABB SNAT604-5761861-2B stands out for its protocol flexibility, supporting both standard industrial protocols (e.g., Modbus) and ABB’s proprietary interfaces. This versatility allows it to connect diverse devices—from legacy sensors to modern smart actuators—without requiring additional converters, reducing hardware complexity. Its high-speed data transfer ensures real-time responsiveness, critical for applications like conveyor belt synchronization in automotive plants or turbine control in power generation.
A standout feature is its diagnostic capability, which provides real-time insights into network health via LED indicators and fault logging accessible through ABB’s engineering software. This proactive monitoring minimizes downtime by flagging issues like signal degradation or communication drops before they escalate. For safety-critical environments, the module supports optional redundancy, enabling seamless failover between primary and backup units to maintain continuous operation.
The module’s compact design optimizes rack space, a key advantage in facilities with densely packed control cabinets. Its rugged build, resistant to vibration and electromagnetic interference, ensures longevity in challenging settings like oil refineries or mining operations. Additionally, its wide-range power input eliminates the need for specialized power supplies, simplifying installation across global sites with varying voltage standards.
Application Scenarios
The ABB SNAT604-5761861-2B is widely deployed in industrial automation to integrate PLCs, HMIs, and field devices. In food and beverage production, it connects packaging machines to central control systems, ensuring precise coordination of filling, labeling, and palletizing processes. Its Modbus compatibility allows seamless integration with third-party equipment like weigh scales or temperature sensors, streamlining quality control.
The ABB SNAT604-5761861-2B is widely deployed in industrial automation to integrate PLCs, HMIs, and field devices. In food and beverage production, it connects packaging machines to central control systems, ensuring precise coordination of filling, labeling, and palletizing processes. Its Modbus compatibility allows seamless integration with third-party equipment like weigh scales or temperature sensors, streamlining quality control.
In energy infrastructure, the module plays a vital role in smart grid management, enabling real-time data exchange between substations and distributed energy resources (e.g., solar inverters or wind turbines). Its high-speed Ethernet connectivity supports predictive maintenance algorithms by transmitting sensor data to cloud-based analytics platforms, reducing equipment failure risks.
For water treatment plants, the SNAT604-5761861-2B links SCADA systems to pumps, valves, and filtration units, ensuring optimal resource allocation and regulatory compliance. Its redundancy support is particularly valuable here, as any downtime could compromise water supply reliability.
Related Models
- ABB SNAT603-CNT – Predecessor model with limited protocol support, replaced by the SNAT604-5761861-2B for broader connectivity.
- ABB SNAT607-MCI – High-integrity analog input module designed to pair with the SNAT604-5761861-2B for complex process monitoring.
- ABB SNAT609-TAI – Isolated bipolar analog output module compatible with the SNAT604-5761861-2B, expanding control capabilities for actuators.
- ABB SNAT7780-GIF – Advanced control module with extended processing power, complementing the SNAT604-5761861-2B in high-complexity systems.
- ABB SPAC320 – Auxiliary relay module that handles alarm signaling and breaker control for the SNAT604-5761861-2B’s communication network.
