Automotion ALC12DE-010-1312 – Compact Double‑Acting Pneumatic Cylinder for Precise Short‑Stroke Motion

From my experience, the model ALC12DE-010-1312 from Automotion appears to be a mini round‑body pneumatic cylinder centered on compact, repeatable linear motion. The code reads like: ALC = aluminum linear cylinder, 12 = 12 mm bore, DE = double‑acting, and 010 = 10 mm stroke. That makes it a solid fit for tight spaces where you still need crisp positioning—pick-and-place nests, light clamping, end‑of‑line checks, or small part ejection. You might notice that it drops into many ISO 6432‑style envelopes, so replacing or standardizing is typically straightforward.

Order Placement Process and Guarantees

• Warranty: 365 days
• Lead time: 1 week if in stock; no more than one month at the latest
• Payment: 50% advance payment; full payment prior to delivery
• Express shipping: FedEx, UPS, DHL

Key Features

• 12 mm bore, 10 mm stroke: Short‑stroke precision for compact assemblies without over‑engineering the actuator.
• Double‑acting (DE): Positive control in both extend and retract for faster cycles and better repeatability.
• Lightweight round‑body design: Typically hard‑anodized aluminum barrel with a stainless piston rod for durability vs. weight.
• Clean air performance: Works well with filtered, dry air; non‑lube service is usually supported for simple maintenance.
• Ports suited to small bores: Commonly M5 threads on this size, making tubing and fittings easy to source.
• Optional position sensing: Magnetic piston variant usually supports compact reed or Hall sensors for end‑of‑stroke feedback.
• Flexible mounting: Foot brackets, rear clevis, or flange mounts are widely available for this form factor.

Technical Specifications

Application Fields

This cylinder size is often chosen where space is tight but reliability still matters. Typical uses include:

• Electronics assembly – precision stops, fixture pins, small part positioning.
• Packaging & labelling – flap tucks, light eject, photo‑eye triggered pushes.
• Test & inspection – gauge engagement, contact probes, pass/fail diverters.
• Medical & lab automation – sample indexing, micro‑conveyance gates.
• General machinery – end‑of‑arm tooling actions on cobots or light robots.

A customer running a benchtop leak‑test fixture told us the short 10 mm stroke was “just right” for repeatable clamping without over‑travel, and they liked that the fittings and sensors were standard stock items.

Advantages & Value

• Compact efficiency: Delivers useful force for its size; ideal for high‑density tooling plates.
• Easy sourcing: Ports, brackets, and sensors are common across many mini‑cylinder lines.
• Compatibility: The envelope typically aligns with ISO 6432‑style mini cylinders, simplifying replacements.
• Lower total cost: Simple pneumatic control and low maintenance reduce lifecycle costs.
• Support when needed: We assist with equivalent mounts, fittings, and sensor choices so you get it running quickly.

Installation & Maintenance

• Air preparation: Use filtered (≈5 μm), dry air. Add lubricator only if your plant standard requires it.
• Mounting & alignment: Keep the cylinder coaxial with the load; use guides if there’s side loading. Verify end‑stop settings before full pressure.
• Fittings & tubing: M5 ports on this size are common—select push‑in or compression fittings rated for 7–10 bar.
• Sensors (if used): Fit magnetic reed/Hall switches to the body band or groove; route cables away from pinch points.
• Commissioning: Start at low pressure, cycle slowly, check for leaks, then ramp to operating pressure.
• Routine maintenance: Inspect seals and rod wiper for wear; keep the rod clean; review cycle counts; replace sensors if switching drift is observed.
• Safety: Lockout/tagout air supply before service; vent residual line pressure; avoid hands near moving travel.

Quality & Certifications

• Typically manufactured to industry quality systems (ISO 9001) with RoHS compliance; CE alignment for pneumatic assemblies is common.
• Warranty: 12 months (365 days) from delivery.

Recommended Supporting Components

• Mounts: Rear clevis, foot bracket, or front/rear flange to suit the ALC12 body.
• Sensors: Slim reed or Hall‑effect switches (5–30 VDC), M8 pigtail or flying lead, for magnetic‑piston variants.
• Fittings & tubing: M5 push‑in fittings with 4 mm OD tubing are common for this bore size.
• FRL unit: Compact filter‑regulator with gauge to stabilize at 4–6 bar for longer seal life.

If you’d like, share your current cylinder brand and mounting style—I can cross‑check dimensions and suggest a drop‑in ALC12DE-010-1312 setup, or an equivalent with the same performance envelope.
