Beckhoff CP2919-0010 – 19-inch Multi‑touch Control Panel for Cabinet Mounting (CP‑Link 4 Single‑Cable HMI)

The Beckhoff CP2919-0010 is a 19-inch built‑in Control Panel designed for demanding machine interfaces. It combines a robust aluminum front with projected capacitive multi‑touch and, in this -0010 option, uses CP‑Link 4 single‑cable technology to carry video and touch over one Cat.6A cable—typically up to 100 m. From my experience, this is a practical way to keep the PC in a protected cabinet while giving operators a crisp, responsive HMI at the machine front.

Order Placement Process and Guarantees

• Warranty: 365 days
• Delivery: 1 week if in stock, no more than one month at the latest
• Payment: 50% advance payment; full payment before delivery
• Express options: FedEx, UPS, DHL

Key Features

• 19-inch multi‑touch display – PCT glass offers precise gestures (zoom, swipe) and a solid, modern operator feel.
• CP-Link 4 single‑cable connection – Video and touch tunneled over one Cat.6A cable; typically up to 100 m when paired with the correct sender.
• Cabinet-front mounting – Clean built‑in look with high front protection for harsh shop-floor conditions.
• Aluminum front, industrial build – Anodized front bezel; robust and easy to clean without yellowing like plastics.
• Front IP65 protection (typical) – With correct mounting and gasket compression, the front resists dust and splashes.
• Beckhoff ecosystem compatibility – Works with Beckhoff Industrial PCs using CP‑Link 4 sender modules (e.g., CU8803 or corresponding interface card).
• Service-friendly – No moving parts in the panel; firmware and configuration are stable once commissioned.

Technical Specifications

Application Fields

You’ll typically see the CP2919-0010 on machine tools, packaging lines, printing and converting equipment, intralogistics systems, and process skids where the PC is housed remotely. One thing I appreciate is how CP‑Link 4 simplifies long runs on large machines—no need to juggle separate DVI and USB extenders.

• OEM machinery (metalworking, plastics, woodworking) needing a durable, glove-friendly HMI
• Packaging, F&B, and pharma lines with washdown zones at the front panel
• Warehouse automation where the PC sits in a climate‑controlled panel and the HMI is on the line
• Process equipment where electrical noise and distance make single‑cable display links attractive

Customer note: “Switching to CP‑Link 4 on the CP2919 cut our cabling time and eliminated the USB extender issues we used to battle,” is the kind of feedback I hear from maintenance teams.

Advantages & Value

• Reliable architecture – Fewer components between PC and panel usually means fewer field failures.
• Lower integration cost – One Cat.6A cable instead of DVI + USB + power. In many cases, installation is quicker and cleaner.
• Long-distance capability – Up to ~100 m with the right sender module helps on large-format machines.
• Compatibility – Native fit with Beckhoff IPCs and CP‑Link 4 senders; easy to standardize across lines.
• Service & lifecycle – Beckhoff panels have stable availability and spare-parts support, which procurement teams tend to value.

Installation & Maintenance

• Cabinet cutout – Follow the Beckhoff CP2919 drawing; ensure uniform clamp pressure so the front achieves IP65.
• Cabling – Use Cat.6A (industrial grade if possible) for CP‑Link 4; avoid tight bends and route away from VFDs and high‑power lines.
• Power – If your CP‑Link 4 sender provides power, a separate 24 V feed isn’t required; otherwise provide 24 V DC (±20%) with proper grounding.
• Ventilation – Provide airflow in the cabinet; avoid direct sunlight or radiant heat on the front glass.
• Safety – De‑energize before service; observe ESD precautions when accessing connectors.
• Routine care – Clean the glass with non‑abrasive, alcohol‑free wipes; firmware updates for the touch controller are rarely needed but should follow Beckhoff guidance.

Quality & Certifications

• CE compliant; typically cULus listed for the North American market
• RoHS and REACH conformant materials
• Manufactured under ISO 9001 quality systems
• Manufacturer’s warranty: 12 months (365 days)

Compatibility tip: Pair this -0010 variant with the appropriate Beckhoff CP‑Link 4 sender (e.g., CU8803 or the IPC’s integrated CP‑Link 4 interface). If you’re unsure about distances or power over the link, share your IPC model and we’ll validate the exact topology.
