Beijer X2MARINE7 (630002505) – 7-inch marine HMI for bridge, engine room, and harsh-deck operations

The Beijer X2MARINE7, part number 630002505, is a compact 7-inch operator panel built for maritime environments where daylight readability, night-time dimming, and rugged sealing genuinely matter. From my experience, this unit fits neatly into helm consoles and engine room panels where space is tight but the need for a reliable, easy-to-read interface is non-negotiable. You might notice that the front is rated for harsh spray and wash-down, while the dual Ethernet and multi-protocol driver support make integration with PLCs, drives, and navigation/auxiliary systems pretty straightforward.

Company’s Order Placement Process and Guarantees

• Warranty period: 365 days
• Delivery: 1 week if in stock; no more than one month at the latest
• Payment: 50% advance; full payment prior to delivery
• Express options: FedEx, UPS, DHL

Key Features

• Marine-focused 7-inch touchscreen – Optimized for bridge and engine room use, with wide viewing angles and anti-glare front for better readability in changing light.
• Wide-range dimming – High-brightness display with dimming down to near-blackout for night operations where glare is a concern.
• Rugged sealing, front IP66/67 – Handles spray, wash-down, and humid, salt-laden air at the front; suitable for panel mounting on exposed consoles.
• 24 V DC power, marine friendly – Typical 18–32 V DC input with low power draw, which works well on stabilized shipboard supplies.
• Dual Ethernet + serial + USB – Convenient for segregating control networks, connecting to PLCs via RS-232/422/485, and handling data via USB devices.
• Rich driver library – In many cases you can connect to Modbus TCP/RTU, EtherNet/IP, PROFINET device-level comms and more without extra gateways.
• Compact footprint – Fits where space is limited; typically used for local engine readouts, tank/ballast monitoring, and auxiliary systems.
• Designed for low maintenance – Solid-state design, fanless operation, and simple front cleaning routines.

Technical Specifications

Related or Supporting Products

• X2 marine 12 – Larger 12-inch variant with more screen area for trend and mimic views; same marine-grade sealing.
• X2 marine 15 – 15-inch panel for bridge consoles where multiple P&IDs or alarm pages are visible at once.
• X2 pro 7 – Similar 7-inch size, general industrial (non-marine) variant; good alternative when marine approvals aren’t required.
• X2 base 7 – Cost-optimized 7-inch HMI for lighter-duty installations; fewer interfaces and lower brightness in many cases.
• 24 V DC DIN-rail power supply (marine-rated) – Stabilized supply to reduce brownouts; choose models with marine approvals for bridge installations.
• Industrial SD/microSD card – For data logging and recipe backups; SLC or industrial-grade TLC types typically recommended.

Installation & Maintenance

• Mounting & cabinet – Use a rigid marine console/panel with correct cut-out; fit the supplied gasket for IP66/67 front sealing. Avoid panel flex that can break the seal.
• Ventilation – Fanless design; ensure natural convection and avoid direct heat sources behind the panel. In engine rooms, keep ambient within the stated range.
• Wiring – 24 V DC stabilized supply; observe proper grounding and shield terminations for serial/Ethernet runs to minimize EMI common at sea.
• Safety – Power down before servicing. Use drip loops on cables and IP-rated glands where exposed to spray.
• Routine care – Clean the front with fresh water and mild detergent; avoid solvents. Check gasket condition annually and replace if hardened or nicked.
• Software upkeep – Keep HMI project files and firmware up to date. Back up recipes/logs to industrial-grade SD. Many teams schedule a quick calibration check and display dimming test during dry-dock.

Quality & Certifications

• CE and RoHS compliant; UL/cUL listings typically available for the X2 family
• Marine approvals commonly include DNV, LR, ABS, BV, KR, NK, CCS (availability can depend on the exact variant and firmware)
• Designed for marine environmental standards such as IEC 60945 for bridge and deck equipment
• Manufacturer’s warranty: 12 months (365 days)

One thing I appreciate is how often this model drops into existing cut-outs and just works—typical feedback from crews is that the dimming range and the front sealing save hassle during night shifts and wash-downs. If your application needs specific protocol drivers or exact approval certificates for class notation, share the checklist and we’ll confirm against 630002505 before shipment.
