Bently Nevada 330130-045-01-00 – 3300 XL Extension Cable for Proximity Transducer Systems

The Bently Nevada 330130-045-01-00 is an original 3300 XL extension cable, typically used to connect a 3300 XL proximity probe to its Proximitor sensor on critical rotating equipment. From my experience, the “-045” length option is a convenient 4.5 m run for most pump trains and small turbines, while the “-01-00” option set usually indicates a standard, non-armored build with factory-fitted coaxial connectors. If you’re standardizing on 3300 XL 5 mm or 8 mm transducer systems, this one drops in cleanly and keeps system accuracy within spec.

Company’s Order Placement Process and Guarantees

• Warranty: 365 days
• Delivery: typically 1 week if in stock; no more than one month at the latest
• Payment: 50% advance payment, full payment for delivery
• Express options: FedEx, UPS, DHL

Key Features

• Engineered for 3300 XL systems – Purpose-built to link 3300 XL probes with their Proximitor sensors, preserving calibration integrity.
• 4.5 m length – A practical run that, in many cases, avoids junction boxes and keeps routing straightforward inside standard panels or conduit.
• Coaxial signal integrity – Impedance-matched cable helps maintain the proximity system’s overall linearity and sensitivity.
• Factory-molded connectors – You might notice that factory terminations reduce noise pickup and save installation time versus field-made ends.
• Rugged jacket – Typically suitable for industrial environments with oils and vibration, especially when routed properly and protected from sharp bends.
• Backwards compatibility – Commonly used across 3300 XL 5 mm and 8 mm probe families on compressors, steam turbines, gearboxes, and fans.

Technical Specifications

Application Fields

Typically found across API-compliant turbomachinery and balance-of-plant assets:

• Steam and gas turbines – shaft vibration and axial position loops
• Compressors and expanders – casing vibration and rotor position
• Pumps and fans – condition monitoring retrofits and OEM builds
• Gearboxes and generators – proximity measurements where accuracy and noise immunity matter

Advantages & Value

• Assured compatibility – Designed for the 3300 XL ecosystem; no guesswork on impedance or connector mating.
• Lower risk during turnarounds – Factory terminations reduce rework; less time chasing intermittent noise or drift.
• Lifecycle cost control – Correct cable length helps avoid splice kits or signal losses that lead to mis-trips.
• Accessible spares strategy – Length options across the 330130-0xx-xx-xx family make stocking simpler.
• Technical support – Guidance on routing, bend radius, and installation do’s/don’ts to keep measurements stable.

Installation & Maintenance

• Environment – Install in a clean, dry cabinet or protected conduit; allow ventilation for associated Proximitor modules.
• Routing – Separate from high-voltage and VFD power lines; maintain gentle bends (no kinks) and strain relief near connectors.
• Wiring – Use the keyed factory connectors; avoid field splicing. Ensure connectors are fully seated; do not overtighten.
• Safety – De-energize associated monitor channels before connect/disconnect. Follow site lockout procedures.
• Routine checks – Inspect jacket for abrasion or oil ingress; verify channel bias/OK status in the monitoring system after any cable change.
• Calibration – The cable itself doesn’t require calibration, but a quick system verification (gap check, linearity spot-check) is recommended after replacement.

Quality & Certifications

• RoHS compliant materials in most configurations
• Manufacturer quality system typically aligned to ISO 9001
• CE marking may apply when used as part of a complete monitoring system
• Manufacturer’s standard warranty plus our 365-day warranty support
