Bently Nevada 350022M_138607-02 – 3500/22M Transient Data Interface with Matching Rear I/O Plate

The 350022M_138607-02 identifies a Bently Nevada 3500/22M Transient Data Interface (TDI) supplied with its revision‑matched rear I/O plate 138607‑02. From my experience, the 22M acts as the rack’s communications hub—collecting static and transient data from all installed monitors and serving it to your condition monitoring software (typically System 1) over Ethernet. You might notice that keeping the OEM rear plate paired with the front module makes cabinet wiring cleaner and, in many cases, shortens commissioning and later swap‑outs.

Company’s Order Placement Process and Guarantees

• Warranty period: 365 days
• Delivery time: 1 week for in-stock; no more than 1 month at the latest
• Payment method: 50% advance payment; full payment for delivery
• Express delivery methods: FedEx, UPS, DHL

Key Features

• Rack communications “brain” – Aggregates monitor data (static and transient) from the 3500 backplane for historian and diagnostics.
• System 1 connectivity – Ethernet link to your condition monitoring software for trending, events, and waveform capture.
• Matched rear I/O 138607‑02 – Revision‑specific rear plate with labeled terminations to keep cabinet wiring tidy.
• Backplane integration – Powered and synchronized through the rack; no separate front‑end PSU wiring.
• Service‑friendly layout – Front plug‑in card with rear terminations usually means quicker checks during outages.

Technical Specifications

Specs reflect common characteristics for a 3500/22M paired with rear I/O 138607‑02. If you share your rack option string and network setup, we’ll confirm the exact fit before shipment.

Application Fields

• Compressor, turbine, and large motor trains feeding real‑time and transient data to System 1
• Balance‑of‑plant assets centralized on a 3500 rack for diagnostics and alarm visibility
• Retrofits moving from local annunciation to historian/enterprise condition monitoring
• Sites standardizing on 3500 hardware for consistent capture and analysis across units

Advantages & Value

• Reliability – Purpose‑built TDI for the 3500 ecosystem; fewer workarounds and cleaner diagnostics.
• Compatibility – Native backplane integration; in many cases a direct, like‑for‑like replacement of an existing 22M.
• Maintenance efficiency – Clear rear terminations and status indicators help technicians move faster.
• Risk control – A 365‑day warranty and traceable labeling support critical spares planning.

Installation & Maintenance

• Rack slotting – Place the 22M in the designated comms slot; mount the 138607‑02 rear plate firmly with captive screws.
• Networking – Connect Ethernet on the rear plate; segregate from high‑EMI cabling and verify link speed/duplex.
• Grounding – Bond rack earth per single‑point practice; maintain shield integrity on adjacent low‑level signal wiring.
• Commissioning – Confirm IP addressing, rack identity, and data collection in System 1; validate transient capture.
• Routine care – Review comms status/alarms, keep terminals tight, and follow site guidance on firmware updates.

Quality & Certifications

• CE and RoHS compliance (typical for Bently Nevada 3500 components)
• UL/cUL suitability for industrial control panels, model dependent
• Manufacturer’s warranty: 12 months from shipment

Field note we hear often: “Replaced the 22M, restored data to System 1, and transient captures were clean again.” Share your rack option string, network settings, and software version, and we’ll confirm the 350022M + 138607‑02 pairing so the changeout is smooth on the first try.
