B&R 3CP380.60-1: High-Performance Industrial Control Relay for Automation Systems
The B&R 3CP380.60-1 is a versatile control relay designed to meet the demands of modern industrial automation systems. Whether you’re managing motor controls, lighting circuits, or HVAC systems, this relay offers dependable switching performance and long-term reliability.
Key Features
- Compact Design: Its small footprint makes it ideal for densely packed control panels, saving valuable cabinet space without compromising functionality.
- High Switching Capacity: Capable of handling up to 10A at 250V AC, this relay ensures efficient operation even in high-load applications.
- Plug-and-Play Compatibility: Designed for seamless integration with standard DIN rail setups, reducing installation time significantly.
- LED Status Indicators: Built-in LEDs provide real-time feedback on relay status, simplifying troubleshooting and diagnostics.
- Wide Operating Temperature Range: From -25°C to +70°C, it performs reliably in extreme environments, making it suitable for outdoor or harsh industrial settings.
Technical Specifications
| Specification | Details |
|---|---|
| Brand/Model | B&R 3CP380.60-1 |
| HS Code | 85364100 |
| Power Requirements | 24V DC (Nominal) |
| Dimensions & Weight | 90mm x 70mm x 65mm, 250g |
| Operating Temperature | -25°C to +70°C |
| Signal Input/Output Types | SPDT (Single Pole Double Throw) |
| Communication Interfaces | None (Relay-based) |
| Installation Method | DIN Rail Mountable |
Application Fields
From my experience, the B&R 3CP380.60-1 shines brightest in industries where precision and durability matter most. For instance, manufacturers use it in conveyor belt systems to manage stop/start operations safely. It’s also commonly found in building management systems for controlling lighting schedules and HVAC equipment. One thing I appreciate is how well it handles repetitive tasks without faltering—something that seems to be a recurring theme in customer feedback.
Advantages & Value
When considering procurement options, the 3CP380.60-1 stands out due to its balance of cost-effectiveness and quality. You might notice that while there are cheaper alternatives, they often lack the robustness needed for continuous operation. This model, however, offers excellent compatibility with existing Siemens ecosystems, which translates into reduced downtime during upgrades. Additionally, its ease of maintenance means lower labor costs over time.
Installation & Maintenance
Installing the 3CP380.60-1 typically requires adherence to standard DIN rail mounting procedures. Ensure proper ventilation around the unit to prevent overheating, especially in enclosed cabinets. Wiring should comply with local electrical codes, and connections must be secure to avoid arcing. Routine maintenance involves periodic cleaning of contact surfaces and firmware checks if applicable. Calibration isn’t usually necessary but can enhance accuracy in critical applications.
Quality & Certifications
This product carries essential certifications such as CE, UL, and RoHS compliance, ensuring it meets global safety and environmental standards. The manufacturer provides a one-year warranty, covering defects in materials and workmanship under normal usage conditions.
Order Placement Process and Guarantees
Warranty Period: 365 days
Delivery Time: Typically within 1 week for in-stock items; no more than one month for special orders.
Payment Method: 50% advance payment, full payment upon delivery.
Express Delivery Methods: FedEx, UPS, DHL available.
