Cameron AAP3798102-00130 Operation Panel – Rugged Operator Interface for Oil & Gas Control Skids
The Cameron AAP3798102-00130 is an industrial-grade operation panel designed for demanding oil and gas environments—think compressor packages, pipeline metering skids, and wellsite control. From my experience, Cameron panels like this are built to keep crews informed and in control, even when conditions aren’t friendly. You might notice that it leans into proven 24 VDC power, straightforward panel-mount installation, and familiar protocols such as Modbus TCP/RTU, which typically makes integration with PLCs and DCS straightforward.
Company’s Order Placement Process and Guarantees
- Warranty period: 365 days
- Delivery time: 1 week for in-stock; no more than one month at the latest
- Payment: 50% advance payment; full payment for delivery
- Express delivery: FedEx, UPS, DHL
Key Features
- Rugged operator interface – Typically panel-mounted with an IP65/NEMA 4X front when gasketed, suitable for topside and shelter applications.
- 24 VDC power – Standard oil & gas control voltage (18–30 VDC nominal) for easy tie-in to skid power systems.
- Simple connectivity – Ethernet for Modbus TCP and serial (RS‑485/RS‑232) for Modbus RTU helps it drop into existing PLC/DCS architectures.
- Clear visualization – HMI-style operation with tactile, predictable response; operators see process values and alarms at a glance.
- Service-friendly design – Front-accessible interface and rear-clamp mounting typically make swap-outs quick during turnarounds.
- Oil & gas focused – Suited to compressor control, pump skids, and metering; often used in brownfield upgrades where compatibility matters most.
Technical Specifications
| Brand / Model | Cameron AAP3798102-00130 (Operation Panel / HMI) |
| HS Code | 8537.10 (Boards, panels, consoles for electric control, ≤1000 V) |
| Power Requirements | 24 VDC nominal (18–30 VDC), ≤20 W typical |
| Dimensions & Weight | Approx. 240 × 170 × 55 mm; ~1.2 kg (panel-mounted unit, typical) |
| Operating Temperature | -20 to +60 °C ambient (front panel rating in most cases) |
| Front Protection | IP65 / NEMA 4X (front, when correctly gasketed and panel-mounted) |
| Signal I/O Types | Process I/O handled via connected PLC/DCS (digital, 4–20 mA, 0–10 V); panel provides HMI/touch input and status indication |
| Communication Interfaces | 1× Ethernet (10/100, Modbus TCP), 1× RS‑485 (Modbus RTU), 1× RS‑232, 1× USB Type‑A (service) |
| Display & Input | TFT LCD HMI with resistive touchscreen (7–10 in class, typical) |
| Installation Method | Panel cutout with rear mounting clamps; use supplied gasket for seal; 24 VDC wiring via screw terminal |
Application Fields
This operation panel fits right into oil & gas control environments where reliability and quick operator action matter:
- Gas compressor packages and booster stations
- Pipeline block valve and metering skids
- Wellhead control, choke management, and separator trains
- Pumps, dehydration units, and produced water handling systems
- Onshore and topside offshore control cabinets and MCC rooms
Advantages & Value
- Reliability in the field – The panelized design and sealed front typically hold up well against dust, humidity, and routine washdowns.
- Compatibility first – Modbus TCP/RTU and 24 VDC make it an easy drop-in for brownfield control upgrades and mixed-vendor sites.
- Lower integration effort – Standard panel cutout installation and simple addressing save commissioning time.
- Lifecycle support – Straightforward spares (gaskets, touch glass, cables) and widely understood protocols reduce downtime risk.
Installation & Maintenance
- Environment – Install in a metal panel or enclosure that meets your site’s standards; allow ventilation or a heat exchanger to keep internal temps within spec.
- Power & wiring – Use a clean 24 VDC supply with proper grounding; shielded twisted pair for RS‑485; segregate signal and power to reduce noise.
- Mounting – Machine the cutout to the recommended size, seat the gasket evenly, and tighten rear clamps uniformly to maintain the IP seal.
- Safety – De-energize circuits before service; lockout/tagout per site policy; verify area classification before opening enclosures.
- Routine care – Wipe the touchscreen with lint-free cloth; check connector tightness during scheduled PMs; back up HMI/PLC configurations; apply firmware updates during planned outages.
Recommended Supporting Components
- 24 VDC DIN‑rail power supply (60–120 W, with surge protection)
- Industrial Ethernet switch (managed, DIN‑rail) for network segmentation
- Shielded Ethernet and RS‑485 cabling rated for the enclosure environment
- Replacement front gasket and touchscreen glass (spares for critical sites)
- Panel door breather/drain to reduce condensation if installed outdoors
Quality & Certifications
- CE compliant for industrial environments
- UL/cUL suitability for industrial control equipment (typical for this class)
- Manufactured under ISO 9001 quality systems
- RoHS-compliant build options in many cases
- Warranty: 365 days from shipment
One thing I appreciate is how panels in this Cameron family tend to integrate quickly with existing PLC logic—customers often tell us commissioning feels more like a swap-and-verify than a ground-up project. If you need exact dimensions, cutout drawings, or compatibility checks with your PLC model, share the skid tag or P&ID reference and we’ll align the configuration before shipment.
