E33NCHA-LNN-NS-00 stepper motor
In the dynamic world of industrial automation, the Kollmorgen E33NCHA – LNN – NS – 00 stands out as a remarkable product, designed to meet the most demanding requirements of modern industrial applications. Kollmorgen, a renowned name in the industry, has crafted this device with precision and innovation, making it a key component in various industrial control systems.
The E33NCHA – LNN – NS – 00 is a high – performance stepper motor that belongs to Kollmorgen’s esteemed E series. This series is well – known for its high efficiency, low loss, and compact design, and the E33NCHA – LNN – NS – 00 embodies these characteristics to perfection. It is engineered to provide reliable and precise motion control, making it an ideal choice for a wide range of industrial scenarios.
|
Label
|
Specification
|
|
Model Number
|
E33NCHA – LNN – NS – 00
|
|
Brand
|
Kollmorgen
|
|
Type
|
Stepper Motor
|
|
Operating Voltage
|
220 V
|
|
Output Frequency
|
30 kHz
|
|
Frame Size
|
Nema 34 (3.38 dia.)
|
|
Mounting Configuration
|
Nema
|
|
Winding Leads
|
4 lead parallel
|
|
Winding Type
|
Additional standards
|
|
Number of Rotor Stacks
|
3
|
|
Shaft Configuration
|
Single / smooth
|
|
Step Accuracy
|
±1.5%
|
|
Resolution
|
1.8°/200 steps per revolution
|
|
Holding Torque
|
6.64 Nm (parallel)
|
|
Detent Torque
|
0.45 Nm
|
|
Moment of Inertia
|
1.77 kg.cm²
|
|
Connection Type
|
System MS connector
|
|
Rated Current
|
8.6 A (parallel)
|
|
Compliant Standards
|
UL
|
One of the key strengths of the Kollmorgen E33NCHA – LNN – NS – 00 is its high – torque density. It can deliver a substantial amount of torque relative to its size, which is particularly beneficial in applications where space is at a premium. This allows for more compact machinery designs without sacrificing performance. The motor also offers smooth operation, with low vibration and noise levels. This makes it suitable for environments where a quiet working atmosphere is essential, such as in certain medical or laboratory equipment.
The compact design of the E33NCHA – LNN – NS – 00 is another major advantage. It can be easily integrated into various devices, fitting neatly into tight spaces. This flexibility in installation is a boon for engineers looking to optimize the layout of their industrial systems. Additionally, the motor exhibits high dynamic response. It can quickly start, stop, and change speeds, making it perfect for applications that require rapid and precise movement, like robotic arms in manufacturing or automated assembly lines.
The Kollmorgen E33NCHA – LNN – NS – 00 finds extensive use across multiple industries. In industrial automation, it plays a crucial role in process control, manufacturing lines, and machinery automation. It ensures that production processes run smoothly and accurately, enhancing overall productivity. In power generation, it is used for the control and monitoring of turbines and generators. By precisely controlling the movement of components, it helps to optimize power generation efficiency and maintain grid stability.
In building automation, the E33NCHA – LNN – NS – 00 contributes to energy – efficient management of heating, ventilation, and air – conditioning (HVAC) systems. It enables precise control of dampers, fans, and other components, reducing energy consumption and improving indoor comfort. In the transportation sector, it is utilized in rail and road traffic management systems for signaling and control. Its reliable performance helps to ensure the safe and efficient movement of vehicles.
There are several related models in Kollmorgen’s product range. The E33NRFC – LNN – NS – 00 is also part of the E hybrid stepper motor series. It features up to 8 leads and offers a step accuracy of ±1.5%. Another model, the E33NCHA – LNN – NS – 01 (hypothetical example), might have enhanced communication capabilities, allowing for more seamless integration with complex industrial networks. The E33NCHA – LNN – NS – 02 could be designed with a higher torque output, suitable for heavy – duty applications. The E33NCHA – LNN – NS – 03 might come with improved energy – efficiency features, reducing power consumption in industrial operations.
Installing the Kollmorgen E33NCHA – LNN – NS – 00 requires careful consideration. When mounting, ensure that it is securely fixed to avoid vibrations that could affect its performance. Proper alignment of the motor with the driven components is also crucial for efficient power transfer. When connecting the power supply and control cables, double – check the connections to prevent any electrical malfunctions. For long – term operation, regular maintenance is essential. Check for any signs of wear on the shaft, bearings, or connectors. Monitor the motor’s temperature and ensure that it is operating within the specified range. Periodically, it is advisable to lubricate the moving parts to reduce friction and extend the motor’s lifespan.
Kollmorgen stands firmly behind the E33NCHA – LNN – NS – 00 with comprehensive warranty coverage. This reflects the company’s confidence in the product’s durability and performance. In case of any issues, Kollmorgen’s global support team is readily available. They can provide remote support for quick troubleshooting or dispatch experienced technicians for on – site service if required. Extensive documentation, including user manuals, technical guides, and installation instructions, is provided to assist users at every stage of the product’s lifecycle. This ensures that industrial automation professionals can rely on the Kollmorgen E33NCHA – LNN – NS – 00 for long – term, reliable operation in their critical industrial processes.
