EL500S-1-60ID 60 mm ID Machine Vision Ring Light – Stable, Uniform Illumination for Inspection Lines

The EL500S-1-60ID is a through-bore LED ring light designed for machine vision and robotics. With a 60 mm inner diameter, it fits neatly around lenses, end-effectors, or nozzles, delivering even, shadow-reduced lighting right where cameras struggle the most—around shiny parts, curved surfaces, and tight tooling. One thing I appreciate is how the broad, uniform field saves time during camera exposure tuning, which in many cases shortens integration time on the line.

Company’s Order Placement Process and Guarantees

• Warranty period: 365 days
• Delivery time: 1 week for in-stock; no more than one month at the latest
• Payment method: 50% advance payment; full payment for delivery
• Express delivery methods: FedEx, UPS, DHL

Key Features

• 60 mm inner diameter (ID) – Slides over standard vision lenses or tooling for close, uniform illumination.
• High-intensity LED array – Delivers bright, even lighting to reduce shadows and hot spots on reflective parts.
• Strobe or continuous modes – Trigger from the PLC/camera for short exposure shots, or run steady for visual assist.
• Intensity control – Typically supports analog (0–10 V) or PWM dimming for fast exposure tuning.
• Industrial 24 VDC power – Fits common control panel supplies; wiring is straightforward.
• Rugged metal housing – From my experience, a solid frame helps maintain alignment in high-vibration cells.
• Clean geometry for vision – The ring design minimizes contrast issues on edges and curved surfaces.

Technical Specifications

Application Fields

• Automated optical inspection on conveyors and rotary tables
• Robotic guidance where the light must wrap around the end-effector or camera
• Surface defect detection on metals, machined parts, and molded plastics
• Barcode/QR/Direct Part Mark reading on reflective or curved components
• Electronics assembly inspection (connectors, solder joints, terminals)
• Pharma/medical device verification where consistent, low-glare lighting is critical

Advantages & Value

• Reliable imaging – Uniform illumination reduces false rejects and cuts down on re-teaching recipes.
• Compatibility – 24 VDC power and standard trigger signals integrate easily with common cameras and PLCs.
• Cost control – Better lighting often means shorter exposure times and faster cycle rates, which typically saves camera costs downstream.
• Serviceability – Simple mounting and accessible connectors make swaps quick during maintenance windows.
• Support-ready – Clear I/O and mounting options simplify documentation for machine builders and auditors.

Installation & Maintenance

• Mounting – Use the front-face holes or a ring bracket; ensure the 60 mm ID clears the lens/barrel or tool. Keep the working distance consistent with your camera setup.
• Power & wiring – Supply regulated 24 VDC. Route I/O cables away from high-noise drives; shielded cables help in most cases.
• Ventilation – Allow airflow around the housing; avoid sealed enclosures without heat dissipation, especially in strobe-heavy duty cycles.
• Safety – Avoid direct eye exposure to high-intensity LEDs. De-energize before adjusting mounts or cleaning the window.
• Routine care – Clean the protective window with lint-free wipes and IPA. Check mounting screws quarterly. Verify trigger/dimming lines after controller firmware updates.

Quality & Certifications

• Conformity: CE, RoHS (typical for industrial LED lighting)
• Manufacturer’s warranty: 12 months

You might notice that ring lights like this often solve tricky glare issues without changing optics. From my experience, that’s where the real value shows—stable images, fewer tweaks, and predictable results across shifts.
