Description
EMERSON 5X00489G01 Control Processor Module
5X00489G01
The EMERSON 5X00489G01 is a high-performance Power Distribution Module (PDM) engineered to deliver stable, redundant power to critical industrial control systems, making it a cornerstone of Emerson’s Ovation™ distributed control architecture. Designed for mission-critical environments like power plants, oil refineries, and water treatment facilities, this module ensures continuous operation by converting incoming AC/DC power into regulated 24V DC outputs, supporting up to 20A of current for field devices such as PLCs, sensors, and actuators. For engineers and plant managers seeking robust power reliability in harsh industrial settings, the 5X00489G01 combines advanced protection features with modular design, ensuring seamless integration into complex automation systems.
| Label | Specification |
|---|---|
| Model Number | 5X00489G01 |
| Brand | Emerson |
| Type | Power Distribution Module (PDM) |
| Input Voltage | 85–264V AC (47–63Hz) or 90–375V DC |
| Output Voltage | 24V DC |
| Output Current | 20A (main) + 1A (auxiliary) |
| Operating Temp | -40°C to +70°C (-40°F to +158°F) |
| Mounting | DIN Rail (35mm) or panel-mountable |
| Weight | Approximately 2.5kg (5.5 lbs) |
| Certifications | CE, UL, CSA, ATEX, IECEx |
| Dimensions | 233mm x 168mm x 64mm (9.17″ x 6.61″ x 2.52″) |
| IP Rating | IP66 (dust-tight and water-resistant) |
| Redundancy Support | Dual-channel hot-swappable configuration |
| Protection Features | Overcurrent, short-circuit, overvoltage, and reverse-polarity protection |
| Efficiency | >90% |
5X00489G01
The 5X00489G01 stands out in industrial environments due to its rugged design and intelligent power management capabilities. Unlike standard power supplies, it incorporates dual-channel redundancy, allowing seamless failover between primary and backup power sources without disrupting operations—a critical feature for applications where downtime is costly. Its IP66-rated enclosure safeguards against dust, moisture, and even high-pressure water jets, ensuring longevity in corrosive or wet environments like chemical processing plants or offshore platforms.
