Emerson KJ1740X1-BA1 HART Communication Module – Smart HART pass-through for plant-wide device diagnostics
The Emerson KJ1740X1-BA1 is a HART communication module designed to bring HART data from field instruments into your control system infrastructure for diagnostics, configuration, and lifecycle management. From my experience, it’s commonly used alongside Emerson DeltaV I/O to enable HART pass-through to asset management tools, so maintenance teams can see device health without interrupting the 4–20 mA control loops. You might notice that it doesn’t demand any exotic wiring—just clean carrier installation and proper loop impedance on your HART-enabled analog channels.
Company’s Order Placement Process and Guarantees
- Warranty: 365 days of coverage from delivery.
- Lead time: 1 week if in stock; no more than one month at the latest.
- Payment: 50% advance payment; full payment prior to delivery.
- Express delivery: FedEx, UPS, or DHL—your choice.
Key Features
- HART pass-through enablement: Makes HART device data available to asset management software while your 4–20 mA loops continue running normally.
- Backplane integration: Plugs into the Emerson carrier; no external power supply typically required, which keeps cabinets clean.
- Device diagnostics: Access to device status, alerts, and configuration parameters to reduce time spent in the field.
- Designed for multi-channel I/O: Works with HART-capable analog channels on the same carrier, so you leverage existing wiring.
- Low-touch maintenance: Module health and communication status presented through the host system in most cases.
- EMC-aware design: Suited for industrial cabinets where grounding and shielding practices matter.
Field note: A utilities customer told us they shaved hours off device checks after enabling HART pass-through with KJ1740X1-BA1. They now review valve positioner diagnostics from the control room before dispatching anyone to the field.
Technical Specifications
| Item | Details |
|---|---|
| Brand / Model | Emerson KJ1740X1-BA1 (HART communication module) |
| HS Code | 853890 (Parts suitable for electrical control/switching apparatus) |
| Power Requirements | Backplane powered from Emerson carrier; no external PSU typically required |
| Dimensions & Weight | Standard Emerson carrier-mounted module; compact footprint for cabinet installation |
| Operating Temperature | 0 to 55 °C (typical for cabinet-mounted control modules) |
| Signal Input/Output Types | HART FSK communication over 4–20 mA analog channels (pass-through; non-intrusive to control signal) |
| Communication Interfaces | Backplane interface to host/controller; HART link to field devices via existing analog loops |
| Installation Method | Plugs into Emerson I/O carrier; typically mounted in a ventilated, grounded DIN-rail control cabinet |
Application Fields
Wherever you depend on smart transmitters or valve positioners, HART visibility pays off. Typical use cases include:
- Oil & Gas: Monitoring device health on critical pressure and flow loops across upstream and midstream assets.
- Chemicals & Petrochemicals: Faster commissioning and loop checks when bringing units online.
- Power Generation: Centralized diagnostics for balance-of-plant instrumentation to cut field rounds.
- Water & Wastewater: Remote verification of level and analytical instruments without opening panels.
- Pharmaceuticals & Food: Streamlined calibration and documentation through asset management systems.
Advantages & Value
- Reliability: Purpose-built for Emerson carriers, which typically means stable backplane communications.
- Compatibility: Works with HART-capable analog loops and common asset management workflows.
- Cost savings: Reduces device check time and unnecessary callouts; fewer trips to the field in many cases.
- Lifecycle support: Keep HART diagnostics aligned with plant upgrades without rewiring loops.
- Procurement simplicity: Standard HS code and a well-established supply chain make import and stocking straightforward.
Installation & Maintenance
- Cabinet environment: Install in a dry, ventilated control cabinet with proper grounding; maintain ambient 0–55 °C where possible.
- Carrier and wiring: Seat the module firmly on the Emerson I/O carrier; secure wiring and retainers to prevent vibration-related faults.
- HART loop integrity: Use shielded twisted pair for analog loops; maintain loop impedance suitable for HART FSK communication.
- EMC and grounding: Single-point grounding and shield termination practices help minimize noise on HART signals.
- Maintenance routine: Periodically review device diagnostics through the host system, clean dust from the cabinet, and back up configuration. Apply firmware or system updates when recommended by Emerson.
- Safety: Follow ESD precautions when handling modules; isolate energy sources before insertion or removal to avoid unintended trips.
Quality & Certifications
- Typically compliant with CE and UL/cUL requirements for industrial control equipment.
- RoHS alignment in many regions; documentation available on request.
- Manufacturer quality systems generally aligned to ISO 9001.
- Our supply is covered by a 365-day warranty and standard functional testing before dispatch.
