EMERSON KJ3002X1-BF1 (12P1732X042) – DeltaV Analog Input I/O Module for 4–20 mA/HART Process Signals

The EMERSON KJ3002X1-BF1, often referenced by part number 12P1732X042, is a DeltaV-series analog input module designed for industrial process measurements. It typically handles 4–20 mA loops with HART pass-through, making it a straightforward drop-in for plant upgrades or spares management. From my experience, this module slots into standard DeltaV I/O carriers and plays nicely with AMS Device Manager for HART diagnostics, which helps maintenance teams close loops faster when transmitters drift or wiring becomes noisy.

Company’s Order Placement Process and Guarantees

• Warranty: 365 days from shipment
• Delivery: 1 week when in stock; no more than one month at the latest
• Payments: 50% advance payment; full payment prior to delivery
• Express options: FedEx, UPS, DHL
• Packaging: ESD-safe, shock-protected; photos available before dispatch if required

Key Features

• DeltaV-native module – Designed for seamless use in EMERSON DeltaV systems, minimizing integration risk.
• 4–20 mA analog inputs with HART – Supports typical process transmitters and HART pass-through for device diagnostics and configuration.
• Status and diagnostics – You might notice clear channel status and fault indication, helping techs find wiring or device issues faster.
• Compact I/O footprint – Fits standard DeltaV I/O carriers; helpful when cabinets are already packed.
• Field-proven reliability – In many cases, these modules run for years with minimal touch, which is what plants typically expect from DeltaV hardware.
• Service-friendly design – Supports routine maintenance and, when properly inhibited, online replacement procedures common to DeltaV installations.

Technical Specifications

Application Fields

Typical use cases include continuous and batch process control: oil & gas (wellhead, separators, pipelines), petrochemical units, refineries, power generation (boiler/auxiliaries), water & wastewater treatment, pulp & paper, and pharmaceuticals. Anywhere you have flow, pressure, level, temperature, pH, or conductivity transmitters on 4–20 mA/HART, this module seems to be a reliable fit.

Advantages & Value

• Compatibility you can bank on – Native DeltaV operation reduces engineering time and avoids quirky integration issues.
• Lifecycle support – Easy tie-in to HART asset management helps cut maintenance hours and unplanned trips to the field.
• Procurement-friendly – A practical spare for installed DeltaV systems; helps standardize your cabinet spares list.
• Cost control – By reusing existing carriers and wiring standards, you typically avoid cabinet rework or new panel builds.
• Technical backup – Documentation and engineering guidance available for commissioning and loop checks.

Installation & Maintenance

• Cabinet & environment – Install on DeltaV I/O carriers in ventilated control cabinets. Keep ambient within 0–55 °C and maintain clean, dry air.
• Wiring practices – Use shielded twisted-pair for 4–20 mA; ground shields at one end to reduce noise. Route analog and power cables separately where possible.
• Loop power – Most deployments use external 24 VDC loop supplies. Verify transmitter burden and total loop resistance before commissioning.
• Safety & ESD – Isolate field power, inhibit channels in DeltaV, and follow ESD handling when inserting/removing modules.
• Commissioning – Perform loop checks at 4/12/20 mA (or 0/50/100%) and validate HART device tags and ranges in AMS/DeltaV.
• Routine maintenance – Periodic terminal re-torque, dust cleaning, and firmware/config backups. Calibrate transmitters per site policy; the module itself typically requires no calibration.

“We swapped in the KJ3002X1-BF1 during a minor outage—HART pass-through came up immediately and our field techs finished checks faster than planned.” — Maintenance Supervisor, chemicals plant

Quality & Certifications

• Compliance: CE; UL/cUL listed; RoHS (typical for DeltaV I/O modules)
• Manufacturer quality system: ISO 9001 (manufacturer-level)
• Warranty: 365 days

One thing I appreciate is how predictable this module is in day-to-day operations. If you’re aligning spares across multiple DeltaV cabinets, standardizing on KJ3002X1-BF1 for 4–20 mA/HART inputs usually keeps both engineering and maintenance on the same page.
