EMERSON Ovation 5X00500G01 – Safety‑Rated Digital Output Module for Critical Interlocks
The 5X00500G01 is a safety‑rated digital output module used in EMERSON Ovation I/O racks. From my experience, plants keep this card on the shelf for ESD valves, trip relays, and other shutdown outputs where deterministic response and simple diagnostics matter. One thing I appreciate is how it drops into the standard Ovation I/O carrier and keeps the field wiring on the terminal assembly, so swap‑outs are typically quick during a planned stop.
Company’s Order Placement Process and Guarantees
- Warranty period: 365 days
- Delivery time: 1 week for in-stock; no more than one month at the latest
- Payment method: 50% advance payment, full payment for delivery
- Express delivery methods: FedEx, UPS, DHL
- Process: Confirm model and quantity → Proforma Invoice → Advance payment → Functional testing and packing → Final payment → Express shipment with tracking
Key Features
- Safety‑rated DO module – Designed for shutdown/interlock duties in Ovation systems where deterministic switching is required.
- Ovation rack compatibility – Plugs into the standard Ovation I/O carrier; field wiring remains on the terminal assembly.
- Channel grouping for protection – Typically arranged in multiple DO channels with per‑channel or per‑group fault indication.
- Diagnostics you can use – You might notice clear status indication to speed up loop checks during commissioning.
- Noise‑resilient design – Suitable for cabinets with solenoids and contactors; works well with coil suppression practices.
Technical Specifications
| Brand / Model | EMERSON Ovation – 5X00500G01 |
| HS Code | 853890 (Parts for switchgear/control equipment) |
| Power Requirements | Supplied via Ovation I/O backplane (typical 24 VDC system supply) |
| Dimensions & Weight | Plug‑in I/O card form factor; weight typically < 0.5 kg |
| Operating Temperature | 0…55 °C cabinet ambient (typical for Ovation I/O) |
| Signal Output Type | Digital outputs for 24 VDC loads; channel count commonly multi‑channel |
| Communication Interfaces | Proprietary Ovation backplane interface; no user Ethernet on module |
| Installation Method | Plugs into Ovation I/O carrier/base; field wiring via matching terminal assembly |
Application Fields
Used where a safety‑rated DO card is preferred for shutdown and interlocks:
- Power generation (boiler trips, turbine auxiliary interlocks)
- Oil & gas and petrochemical ESD/PSD outputs (solenoids, trip relays)
- Metals, mining, and cement lines with critical stop functions
- Modernization projects in existing Ovation cabinets
Advantages & Value
- Reliability: Stable output behavior with clean switching into inductive loads when suppression is used.
- Compatibility: Keeps the installed base intact—no rewiring in most cases since the terminal assembly stays put.
- Cost savings: Like‑for‑like replacement avoids unnecessary engineering or cabinet modifications.
- Support: We can run power‑up and basic loop checks before shipment and share a quick test report.
“Swapped a suspect DO card on our ESD panel with 5X00500G01. Loop checks were straightforward and the nuisance trip counter has been flat since.” — I&C engineer, combined‑cycle power station
Installation & Maintenance
- Cabinet environment: Clean, dry, and ventilated Ovation rack; maintain ambient within spec.
- Handling: Use ESD protection; inspect edge connector and carrier contacts for wear before insertion.
- Wiring: Keep field wiring on the terminal assembly; apply flyback diodes or surge suppressors on DC coils to protect outputs.
- Power‑up checks: Verify system 24 VDC supply tolerance and ground scheme; confirm status LEDs before placing outputs in service.
- Routine maintenance: Quarterly dust removal, connector reseat checks, and proof testing of safety outputs per site procedures.
- Notes on safety use: SIL capability and diagnostic coverage depend on system design and revision—typically verified against your Ovation safety manuals.
Quality & Certifications
- Manufacturing quality: Produced under ISO 9001 quality systems (typical for EMERSON Ovation hardware).
- Compliance: Suitable for installation in CE/UL compliant control panels; RoHS status depends on production year and region.
- Warranty: 365‑day warranty from shipment date.
If you can share the carrier type, terminal assembly part number, and the output load details (coil current, suppression method), we’ll double‑check 5X00500G01 compatibility and prepare functional test results before dispatch.
