EMERSON SE3008 KJ2005X1-MQ2 13P0072X082 Digital Control System Automation Spare Parts Module
| Model Number | SE3008 KJ2005X1-MQ2 13P0072X082 |
| Brand | EMERSON |
| Type | Analog/Digital I/O Module for DeltaV DCS |
| Signal Types Supported | Analog Inputs (AI), Analog Outputs (AO), Digital Inputs (DI), Digital Outputs (DO) |
| Input Voltage (Terminal Block) | 24 VDC (field power) |
| Operating Temperature | -40°C to 70°C |
Tel: +86 17350880093
Whatsapp: 17350880093
E-mail : sales@fyplc.com
Zhangzhou Fengyun Electrical Equipment Co.LTD
Categories: EMERSON
Description
EMERSON SE3008 KJ2005X1-MQ2 13P0072X082 Digital Control System Automation Spare Parts Module
EMERSON SE3008 KJ2005X1-MQ2 13P0072X082: High-Reliability I/O Module for DeltaV DCS Systems
In the complex landscape of industrial automation, the EMERSON SE3008 KJ2005X1-MQ2 13P0072X082 stands as a cornerstone I/O module designed to enhance the connectivity and performance of Emerson’s DeltaV Distributed Control System (DCS). Engineered for precision and durability, this module serves as a critical link between field devices—such as sensors, valves, and actuators—and the DeltaV controller, ensuring seamless data exchange and reliable process control. Ideal for industries ranging from oil & gas to pharmaceuticals, the SE3008 KJ2005X1-MQ2 excels in high-stakes environments where system uptime and data accuracy are non-negotiable.
As part of Emerson’s extensive DeltaV ecosystem, this module is optimized for analog and digital input/output (I/O) applications. It supports a wide range of signal types, including 4–20 mA analog signals, thermocouples, RTDs, and discrete (on/off) signals, making it versatile for monitoring and controlling diverse industrial processes. The 13P0072X082 designation often refers to specific terminal block configurations, ensuring compatibility with legacy and modern field wiring standards. Whether deployed in a chemical plant’s reactor control system or a food processing facility’s packaging line, this module delivers the reliability needed to maintain production efficiency and safety.
| Label | Specification |
|---|---|
| Model Number | SE3008 KJ2005X1-MQ2 13P0072X082 |
| Brand | EMERSON |
| Type | Analog/Digital I/O Module for DeltaV DCS |
| Signal Types Supported | Analog Inputs (AI), Analog Outputs (AO), Digital Inputs (DI), Digital Outputs (DO) |
| Input Voltage (Terminal Block) | 24 VDC (field power) |
| Operating Temperature | -40°C to 70°C |
| Communication | Proprietary DeltaV bus (100 Mbps redundant Ethernet) |
| Mounting | Rack-mounted within DeltaV control cabinets |
| Certifications | ATEX, IECEx (hazardous area compliance), UL, CE |
| Dimensions | [Typical DeltaV module size: ~200 mm x 150 mm x 50 mm] |
| Channel Count | 8 channels (configurable as AI/AO/DI/DO) |
| Isolation | Galvanic isolation for each channel |
Functional Strengths & Design Advantages
The EMERSON SE3008 KJ2005X1-MQ2 is engineered with industrial resilience in mind. Its galvanic isolation per channel protects against electrical surges and ground loops, ensuring signal integrity even in noisy environments with high electromagnetic interference (EMI). The module’s hot-swappable design allows for maintenance or replacement without powering down the entire system, minimizing downtime during routine servicing—a critical feature for 24/7 operations.
One of its standout advantages is configurability. Engineers can tailor each of the 8 channels to specific signal types (e.g., analog temperature readings from RTDs or digital status signals from valves), eliminating the need for multiple specialized modules. This flexibility reduces hardware complexity and costs while simplifying inventory management. The module also supports advanced diagnostics, such as channel-level fault detection and signal drift alerts, enabling proactive maintenance and reducing mean time to repair (MTTR).
The 13P0072X082 terminal block complements the module’s performance with secure, easy-to-access wiring connections. Its rugged design withstands vibration and environmental stress, ensuring reliable connectivity in harsh industrial settings.
Industrial Use Cases & Value Scenarios
In oil & gas refining, the SE3008 KJ2005X1-MQ2 monitors critical process variables like pressure and flow rate from field transmitters, transmitting real-time data to the DeltaV controller for closed-loop control of pumps and valves. In pharmaceutical manufacturing, it controls sterile processing environments by managing analog signals from pressure sensors in cleanrooms and digital signals from batch processing valves, ensuring compliance with FDA and cGMP standards.
For water treatment plants, the module optimizes chemical dosing systems by integrating analog inputs from pH sensors and driving analog outputs to metering pumps, maintaining precise chemical concentrations. Across these industries, the module addresses key challenges like signal degradation, equipment downtime, and regulatory compliance, delivering benefits such as:
- Enhanced Process Stability: Consistent signal handling reduces variability in production outcomes.
- Cost Efficiency: Fewer specialized modules and simplified wiring lower installation and maintenance costs.
- Scalability: Seamless integration with DeltaV’s modular architecture allows easy expansion of I/O capacity.
Compatible and Related Models
- EMERSON SE3016 KJ2005X1-MQ3 13P0072X083 – 16-channel variant for high-density I/O applications.
- EMERSON SE3008 KJ2005X1-MQ1 13P0072X081 – Earlier revision with basic I/O capabilities (compatible with legacy DeltaV systems).
- EMERSON SE3008 KJ2020X1-MQ2 – Supports Foundation Fieldbus for smart instrumentation integration.
- EMERSON SE3008 KJ2005X1-MQ4 – Enhanced with safety-instrumented system (SIS) functionality for SIL-rated applications.
- EMERSON 13P0072X080 – Simplified terminal block for basic I/O configurations.
Setup & Service Guidance
Installation involves sliding the module into a DeltaV rack and securing it with captive screws. Field wiring is connected via the 13P0072X082 terminal block, with clear labeling for each channel to facilitate troubleshooting. Key installation considerations include:
- Shielding: Route signal cables separately from power cables to minimize EMI.
- Grounding: Ensure proper chassis and signal grounding to prevent noise-induced errors.
- Redundancy: Leverage DeltaV’s dual-bus architecture for fault tolerance in critical applications.
For maintenance, periodic checks should include:
- Visual Inspections: Look for loose connections or corrosion on the terminal block.
- Diagnostic Tests: Use DeltaV’s built-in tools to verify channel accuracy and isolation.
- Firmware Updates: Regularly update via DeltaV Workbench to access new features and security patches.
- Spare Module Availability: Keep a spare on hand for quick replacement during unexpected faults.
Warranty & Support Coverage
Emerson backs the SE3008 KJ2005X1-MQ2 13P0072X082 with a 3-year warranty, covering defects in materials and workmanship. Customers can access Emerson’s global support network for 24/7 technical assistance, including remote diagnostics and on-site service from certified technicians. Comprehensive documentation—such as the DeltaV I/O Module Configuration Guide and Safety Data Sheets—is available via Emerson’s Exchange software platform, ensuring users have the resources to optimize module performance and compliance.
In summary, the EMERSON SE3008 KJ2005X1-MQ2 13P0072X082 exemplifies Emerson’s commitment to robust, adaptable automation solutions. By combining high-precision I/O capabilities with rugged design and seamless DeltaV integration, this module empowers industries to achieve operational excellence, safety, and scalability in an increasingly connected industrial landscape.
