FANUC A06B-6110-H011 Power Supply Module – Stable 200V-class backbone for αi servo/spindle systems
The FANUC A06B-6110-H011 is a Power Supply Module from the αi series (often referred to as PSM-11). From my experience, this unit is a dependable “front end” for 200V-class FANUC αi servo and spindle amplifiers, providing the regulated DC link and regenerative handling your machine needs to run cleanly and keep downtime in check. You might notice that it drops in neatly when upgrading or replacing older α power supplies, which makes retrofit work much easier in many cases.
Company’s Order Placement Process and Guarantees
- Warranty: 365 days
- Delivery time: Typically 1 week if in stock; no more than 1 month at the latest
- Payment: 50% advance payment; full payment prior to delivery
- Express options: FedEx, UPS, DHL
Key Features
- αi-series compatibility: Designed to power FANUC αi servo and spindle amplifiers in 200V-class systems.
- Regenerative energy handling: Built-in control for braking energy; supports external regen resistor when the axis load demands it.
- Stable DC link: Provides a clean, reliable DC bus for multi-axis machines, which typically translates into smoother motion and fewer nuisance trips.
- Protection and self-diagnostics: Over-voltage, over-current, and over-heat protections with status/alarm indication to speed up troubleshooting.
- Service-friendly layout: Clear terminal labeling and front access simplify panel work and field replacement.
- Drop-in replacement potential: In many cases, a straightforward swap on FANUC 200V-class α/αi control cabinets.
Technical Specifications
| Brand / Model | FANUC A06B-6110-H011 (αi Power Supply Module, commonly PSM-11) |
| HS Code | 8504.40 (Static converters) |
| Power Requirements | 3-phase 200–240 VAC, 50/60 Hz (200V-class systems) |
| DC Link / Output | DC bus for FANUC αi servo/spindle amplifiers; regenerative energy control; external resistor terminals available |
| Operating Temperature | 0–55°C (non-condensing); derating may apply above 45°C |
| Dimensions & Weight | PSM-11 frame size; typically around mid-compact form factor; weight approximately 5 kg |
| Signal I/O Types | DC link bus to αi amplifiers; status/alarm outputs; regen resistor interface |
| Communication Interfaces | None on the PSM itself; system communication via connected αi amplifiers (e.g., FSSB from CNC) |
| Installation Method | Panel-mounted inside control cabinet (vertical orientation); bolted mounting points; maintain ventilation clearance |
| Protections | Over-voltage, over-current, over-temperature; LED/alarm codes for diagnostics |
Application Fields
This module is commonly used in FANUC-based machining centers, CNC lathes, drilling/tapping lines, grinding machines, and small robotized cells. One thing I appreciate is how it keeps mixed servo/spindle setups stable on 200V-class machines—especially on older lines where you want modern reliability without a total cabinet redesign.
- OEM machine builds and lifecycle replacements on FANUC α/αi platforms
- Retrofit projects upgrading power sections while retaining existing CNC and motors
- High-duty-cycle cells that need reliable regenerative handling
- Service spares to shorten unplanned downtime windows
Advantages & Value for Procurement
- Reliability: Proven αi architecture that, in most cases, runs for years with minimal intervention.
- Compatibility: Works with matching FANUC αi servo/spindle modules, reducing integration friction.
- Cost control: Drop-in form factor helps avoid cabinet rework and long commissioning time.
- Serviceability: Clear alarm behavior and accessible terminals make troubleshooting faster.
- Availability options: Stock and expedited logistics (FedEx/UPS/DHL) when downtime is critical.
Installation & Maintenance
For installation, I typically recommend a clean, sealed control cabinet (IP54 or better) with vertical mounting and clear airflow. Keep power and signal wiring separated, bond PE/ground with low impedance, and follow torque specs on DC link and mains terminals. If your cycle has heavy decel, plan for an external regenerative resistor sized to the duty.
- Environment: 0–55°C, non-condensing; avoid conductive dust and oil mist.
- Ventilation: Maintain top/bottom clearance; ensure cabinet fans/filters are clean.
- Wiring: Use appropriately rated cables; verify phase rotation and correct DC link polarity to amplifiers.
- Safety: Lockout/tagout; wait for DC bus discharge before servicing (indicator LEDs to confirm).
- Maintenance: Periodic dust cleaning, terminal retorque checks, and visual inspection for heat discoloration.
- Software: The PSM itself typically needs no firmware updates; ensure CNC/drive software compatibility when replacing legacy units.
