GE DS200DCFBG1BJB Power Supply Board – Stable low-voltage DC for GE drive and Mark V control cabinets

The GE DS200DCFBG1BJB is a DS200-series power supply board that typically sits at the heart of GE drive and Mark V-based control sections, converting cabinet control power into clean, regulated DC rails for logic, I/O, and peripheral cards. From my experience, this model is favored when you need dependable control-level power, straightforward diagnostics, and a drop-in replacement path for existing GE DS200 installations. You might notice that it carries the familiar DS200 mounting pattern and PL-style connectors, making swaps quick during scheduled outages.

Company’s Order Placement Process and Guarantees

• Warranty: 365 days coverage
• Lead time: 1 week if in stock; no more than one month at the latest
• Payment: 50% advance payment; full balance prior to delivery
• Express options: FedEx, UPS, DHL

Key Features

• Control-level DC outputs – Designed to supply stable low-voltage rails (commonly +5 V, ±15 V, +24 V) for logic and analog sections.
• Cabinet-friendly input – Typically powered from the cabinet’s control power transformer (115–230 VAC, 50/60 Hz), easing integration.
• Status LEDs and test points – Quick visual checks and convenient measurement points simplify troubleshooting on the floor.
• Rugged DS200 build – Proven form factor, standoff mounting, and robust connectors for industrial environments.
• Serviceable design – From my experience, field techs appreciate the clear connector mapping and labeled reference points for fast swap-outs.

Technical Specifications

Application Fields

This board is typically deployed in GE industrial drives and Mark V-based turbine or process control cabinets where clean, regulated logic power is critical. It fits neatly in applications such as fan/pump VFD sections, compressor control skids, and turbine auxiliary panels. In many cases, maintenance teams keep one on hand as a spare to minimize downtime during a supply fault or brownout event.

Advantages & Value

• Reliability – Stable rails reduce nuisance trips and intermittent logic errors under noisy mains conditions.
• Compatibility – DS200 footprint and connectors streamline retrofit or replacement in existing GE cabinets.
• Cost control – A focused replacement board is often more economical than reworking the entire control section.
• Service support – Clear LEDs and test points cut mean time to repair; techs locate issues faster.

Installation & Maintenance

• Environment – Install in a ventilated control cabinet (IEC/NEMA enclosure), away from high-heat sources and conductive dust.
• Wiring – Use the designated PL headers; verify CPT input and ground integrity before energizing. Keep low-voltage runs separated from high-power cabling.
• Safety – De-energize, lockout/tagout, and discharge stored energy before handling. Observe ESD precautions.
• Routine checks – Periodically confirm rail voltages at test points, inspect connectors for oxidation, and clean dust with dry, oil-free air.
• Lifecycle practice – If your site uses firmware-dependent adjunct boards, align maintenance windows to check revision compatibility and cabinet grounding quality.

Quality & Certifications

Factory-original DS200 boards typically align with industrial standards and are commonly deployed in CE/UL-marked systems. Many users operate them within ISO 9001-managed facilities, and materials are generally RoHS-conscious for spares. Manufacturer’s warranty practices vary by region and channel; for this supply, the warranty period is 365 days as stated above.

Related / Supporting Components

In most cabinets, the DS200DCFBG1BJB works alongside other DS200-series boards and cabinet hardware. Common companions include:

• Control Power Transformer (CPT) assembly – feeds the AC input to the DCFB power stage.
• Harness sets with PL-style connectors – interconnect to logic and analog cards drawing +5 V/±15 V.
• DS200-series control boards (varies by frame) – for example, drive control or I/O interface cards that consume the regulated rails.
