GE IS230TDBTH6A Digital Input Module Control Board
IS230TDBTH6A
As a high-performance digital I/O module, the IS230TDBTH6A specializes in processing binary signals from sensors, switches, and actuators, translating them into actionable data for control algorithms. Its primary function is to ensure that industrial processes—from power generation and oil refining to manufacturing and beyond—operate with maximum efficiency and minimal downtime. By providing robust signal isolation and high-speed communication, the module safeguards against electrical interference and ensures the integrity of data transmission, even in harsh industrial environments.
| Label |
Specification |
| Model Number |
IS230TDBTH6A |
| Brand |
GE |
| Type |
Digital I/O Module |
| Input Voltage |
24 VDC (nominal) |
| Operating Temp |
-40°C to +70°C |
| Communication |
Serial interface via Mark VIe backplane |
| Mounting |
Rack-mountable (compatible with Mark VIe chassis) |
| Weight |
0.7 kg |
| Certifications |
CE, UL, CSA, ATEX (Zone 2 certified) |
| Dimensions |
107 mm x 160 mm x 200 mm |
| I/O Channels |
32 configurable digital I/O (expandable in multiples of 32) |
| Signal Type |
TTL/CMOS compatible, optically isolated |
| Response Time |
<1 ms (typical) |
| Current Rating |
200 mA per channel |
IS230TDBTH6A
The GE IS230TDBTH6A distinguishes itself through its exceptional signal processing capabilities and rugged design. Its 32 configurable I/O channels offer unparalleled flexibility, allowing engineers to customize input and output assignments based on specific application requirements. This adaptability makes it suitable for a wide range of industrial scenarios, from monitoring conveyor belt sensors in a factory to controlling valve actuators in a chemical plant.
Optical isolation between channels and ground provides robust protection against electrical noise and voltage spikes, ensuring reliable operation in environments with high electromagnetic interference (EMI). This isolation also enhances safety by preventing ground loops and minimizing the risk of signal corruption. The module’s high-speed response time of less than 1 millisecond enables real-time control and monitoring, critical for applications requiring rapid decision-making, such as emergency shutdown systems or turbine speed regulation.
IS230TDBTH6A
Designed for industrial durability, the IS230TDBTH6A features a compact, DIN-rail mountable enclosure that resists vibration, shock, and temperature extremes. Its wide operating temperature range ensures consistent performance in both frigid outdoor environments and high-temperature industrial settings. Additionally, the module’s hot-swappable design simplifies maintenance and reduces downtime, as it can be replaced without powering down the entire system.
In power generation plants, the
GE IS230TDBTH6A plays a pivotal role in monitoring and controlling critical systems. For example, it interfaces with sensors that detect the position of steam turbine valves, the status of circuit breakers, and the level of cooling water in condensers. By providing real-time data to the control system, the module enables precise regulation of turbine speed and power output, optimizing efficiency and reducing fuel consumption. In the event of an emergency, its fast response time ensures that safety systems can be activated immediately, preventing equipment damage and ensuring operator safety.
