GE PACSystems RX3i IC695CBL001 – Short Expansion/Backplane Interconnect Cable for RX3i Racks

The GE IC695CBL001 is the short-length expansion/backplane interconnect cable for PACSystems RX3i. In many cases it’s used to link a CPU/main rack to an adjacent expansion rack, or to bridge modules with the RX3i expansion port inside the same cabinet. One thing I appreciate is how tidy it keeps a panel layout when the racks are side-by-side—you avoid excess slack and reduce the chance of noise pickup in high-EMI enclosures.

Our Order Placement Process and Guarantees

• Warranty: 365 days
• Delivery: 1 week if in stock, no more than one month at the latest
• Payment: 50% advance payment; full payment prior to delivery
• Express: FedEx, UPS, DHL
• Verification: We verify model/firmware compatibility before shipment when requested

Key Features

• Designed for PACSystems RX3i – Matches the RX3i expansion/backplane interconnect, avoiding third‑party cable uncertainties.
• Short link for adjacent racks – Typically the 1 ft (approx. 0.3 m) option; ideal when racks are mounted side-by-side in the same cabinet.
• Factory-terminated, keyed connectors – You might notice the fit is snug and alignment is obvious, which helps prevent mis-mating in tight spaces.
• Shielded construction – From my experience this reduces crosstalk when you’re routing past power devices or contactors.
• Panel-friendly bend radius – Easy to route along cable duct with minimal stress on the connectors.
• Service-friendly – Clear labeling supports quick maintenance; swap-outs usually take minutes.

Technical Specifications

Related or Supporting Products

• IC695CBL002 / IC695CBL003 / IC695CBL004 – Longer RX3i expansion cables (for racks spaced further apart).
• IC695CHS012 / IC695CHS016 – RX3i rack chassis (12- and 16-slot); choose based on I/O count and layout.
• IC695CPL410, IC695CPU315 – RX3i CPUs; CPL410 adds integrated Ethernet and higher performance in many cases.
• IC695PSA040 – RX3i power supply commonly paired with CPU racks.
• IC695NIU001 – RX3i Network Interface Unit for remote/expanded rack architectures.

Installation & Maintenance

• Cabinet standards: Install in an industrial control panel with proper wire duct and grounding. Keep low-voltage signal routing separate from high-voltage power where possible.
• Ventilation: Maintain airflow around racks; avoid tight bends right at the connector. You might notice fewer intermittent issues when the cable isn’t under mechanical stress.
• Wiring practice: Observe the minimum bend radius; route the cable away from VFD outputs and contactor coils to reduce EMI coupling.
• Safety precautions: Power down the system before connecting/disconnecting. Verify the expansion port labeling on each rack.
• Routine checks: Inspect connectors during scheduled maintenance for latch integrity and insulation wear; wipe dust with a dry, lint-free cloth.
• Firmware/updates: No firmware on the cable; however, keeping RX3i CPU and communications modules updated typically improves expansion-bus stability.

Quality & Certifications

• CE compliant (industrial EMC)
• RoHS compliant materials
• UL/CSA usage typically supported as part of the RX3i system
• Manufacturer’s quality controls and full traceability
• 365-day warranty (from us) with advance replacement support when stock allows

Field note from a maintenance lead using this cable in a bottling line: “Switching to the IC695CBL001 for the side-by-side racks cleaned up our cabinet and stopped random expansion faults we saw with a longer run. It’s a small change that made the diagnostics quiet again.”
