HIMA X-SB01-985210207 – HIMax System Separator/Slot Barrier for Safe, Clean Backplane Layouts

The HIMA X-SB01-985210207 is a passive separator/slot barrier designed for the HIMax safety PLC platform. From my experience, this small accessory does a big job: it helps segment module groups on the backplane, improves EMC shielding and touch protection, and keeps expansion areas reserved and clearly identified. You might notice that installers often use it to maintain clean airflow and protect unused slots during staged commissioning.

Order Placement Process and Guarantees

• Warranty: 365 days
• Lead time: 1 week if in stock; no more than one month at the latest
• Payment: 50% advance payment; full payment for delivery
• Shipping: FedEx, UPS, DHL
• Process: Confirm model and quantity → receive formal quotation → issue PO and prepayment → packing/testing → balance payment → express shipment with tracking

Key Features

• Passive safety partition – Provides a physical barrier between HIMax modules, supporting safe segregation and tidy slot management.
• No power, no I/O – Fully passive piece; nothing to configure, nothing to power, nothing to commission.
• EMC and touch protection – Typically helps reduce interference and prevents accidental contact with unused backplane areas.
• Slot reservation for expansion – Keeps future capacity protected and clearly labeled so upgrades go faster and cleaner.
• Backplane-aligned fit – Designed for easy insertion into HIMax X-BP backplane guides; installation is quick and tool-light in most cases.
• Service-friendly identification – Straightforward labeling area so maintenance teams know which zone or segment is reserved.

Technical Specifications

Application Fields

Typical users are those running HIMax in high-integrity environments. We often see X-SB01 barriers installed in:

• Oil & Gas ESD/FGS cabinets to segregate critical I/O groups by unit or zone
• Chemical and petrochemical SIS skids where staged expansion is planned
• Power generation safety systems (turbine protection, boiler protection) to keep layouts disciplined
• Pharma and fine chemicals lines requiring EMC-conscious panel design

A maintenance lead recently told us this “saves us hours during shutdowns—unused slots stay clean and clearly reserved, so there’s less second-guessing on site.”

Advantages & Value

• Reliability: Protects the backplane from dust and incidental contact, which in many cases reduces intermittent faults caused by contamination.
• Compatibility: Made for the HIMax ecosystem; aligns with X-BP backplanes and standard module spacing.
• Cost control: Low-cost accessory that helps safeguard high-value I/O and CPU modules.
• Future-proofing: Simplifies phased expansions—reserved slots are already protected and labeled.
• Easy handling: No firmware, no setup, no utilities—procurement and installation stay simple.

Installation & Maintenance

• Cabinet & mounting: Install within a clean, ventilated control cabinet. The HIMax backplane is typically DIN-rail or panel mounted—insert the X-SB01 into the designated slot guides.
• Wiring clearances: Keep power and signal wiring routed away from unused slots; maintain EMC best practices and proper grounding.
• Safety: De-energize the rack before inserting or removing accessories. Observe ESD precautions when working around populated modules.
• Routine checks: Periodically inspect for dust buildup; clean with a non-conductive brush or vacuum. Verify labels remain legible. No calibration or firmware updates are required for this accessory.

Quality & Certifications

• CE conformity for industrial environments (as part of the HIMax system)
• TÜV-certified HIMax platform for SIL3 applications per IEC 61508 (system-level)
• RoHS-compliant supply chain
• Supplier warranty: 365 days from delivery

Compatible Accessories & Related Modules

The X-SB01 is typically paired with common HIMax components. If you’re planning a bundle, these are frequently requested together:

• HIMA X-BP 08 / X-BP 16 – Backplanes for 8 or 16 module slots
• HIMA X-PSU 01 – System power supply module for HIMax racks
• HIMA X-CPU 31 – Central processing unit for HIMax controller
• HIMA X-DI 16 01 / X-DO 16 01 – Discrete input/output modules for field signals
• HIMA X-COM 01 – Communication interface module for higher-level networks

One thing I appreciate is how this simple barrier tends to keep cabinets inspection-ready. In many cases, it pays for itself by preventing inadvertent contact during hectic turnaround work.
