Honeywell 05701-A-0301 Channel Control System Card
05701-A-0301
The Honeywell 05701 – A – 0301 is primarily designed for applications that require single – channel control within industrial automation systems. Its core function is to receive input signals, process them, and generate appropriate output signals to control actuators, valves, or other devices in the industrial process. Whether it’s regulating the flow of fluids in a chemical plant, controlling the speed of motors in a manufacturing facility, or maintaining precise environmental conditions in a pharmaceutical production area, this control card plays a vital role. By providing real – time control and feedback, it enables operators to maintain tight control over processes, respond promptly to any deviations, and ensure that the overall system operates within the desired parameters. This level of precision control no
|
Label
|
Specification
|
|
Model Number
|
05701 – A – 0301
|
|
Brand
|
Honeywell
|
|
Type
|
Single – Channel Control Card
|
|
Channel Count
|
Single
|
|
Control Type
|
Digital
|
|
Operating Voltage Range
|
24 V DC to 28 V DC
|
|
Frequency Response
|
20 Hz to 20 kHz
|
|
Response Time
|
Less than 1 ms
|
|
Input/Output
|
8 Input, 2 Output
|
|
Communication Interface
|
RS – 485
|
|
Power Consumption
|
Max. 10 W
|
|
Temperature Range
|
– 40 °C to + 70 °C
|
|
Reliability Rating
|
MTBF > 100,000 hours
|
|
Physical Dimensions
|
Length: 17 cm, Width: 2.5 cm, Height: 11.2 cm
|
|
Weight
|
0.165 kg
|
|
Certifications
|
CE, UL, CSA
|
|
Input Types
|
0 – 10 V DC and 4 – 20 mA
|
05701-A-0301
The RS – 485 communication interface should be wired according to the standard, with proper termination resistors installed at the ends of the communication bus to prevent signal reflections. The card should be mounted in a location that is free from excessive vibration, heat, and electromagnetic interference. If the installation environment is prone to vibrations, using vibration – damping mounts can help protect the card and ensure stable operation. It is also advisable to install the card in a well – ventilated area to prevent overheating, especially in environments where multiple control cards are installed in close proximity.
