Honeywell Saia PCD4.D1XX-463665500 – Digital Input Expansion for PCD4 PLC Systems

The Honeywell Saia PCD4.D1XX-463665500 is a digital input module designed to expand the input capacity of PCD4-based controllers. In many cases, it’s used to bring 24 VDC field signals (switches, sensors, dry-contact relays) into the PLC with reliable isolation and clear status indication. From my experience, teams in HVAC plants, water treatment skids, and OEM machinery pick the D1xx variants when they need stable, noise-robust DI points on legacy PCD4 racks without reworking the whole control panel.

One thing I appreciate is how these modules typically slot straight onto the PCD4 backplane, so wiring stays clean and service-friendly. You might notice that channel count and exact electrical characteristics can vary by sub-variant within the D1xx family, but the core purpose remains the same: dependable 24 VDC digital input acquisition for PCD4 systems.

Our Order Placement Process and Guarantees

• Warranty: 365 days
• Delivery: typically 1 week if in stock; no more than 1 month at the latest
• Payment terms: 50% advance payment; full payment before delivery
• Express options: FedEx, UPS, DHL

Key Features

• PCD4 backplane compatibility – Built to integrate with Saia PCD4 PLC systems for straightforward expansion.
• Digital input focus (24 VDC) – Typically accepts standard 24 VDC field signals from switches, contacts, and sensors.
• Channel density – D1xx variants commonly provide a moderate-to-high number of DI points; ideal for compact panels.
• Optical isolation – In many cases, inputs are opto-isolated to reduce noise coupling and enhance reliability.
• Status LEDs – Quick at-a-glance diagnostics without connecting a laptop, speeding up commissioning.
• Serviceable wiring – Usually screw or cage-clamp terminals that maintenance teams are comfortable with.
• Stable operation – Designed for industrial environments where EMI and switching spikes are routine.

Technical Specifications

Where it fits best

Typical applications include HVAC plant IO (fans, pumps, dampers), utility monitoring, small water/wastewater panels, and OEM equipment where a compact DI slice is needed. A building contractor told us the D1xx saved him a weekend on a retrofit—he reused the PCD4 rack, landed new sensor wiring, and was back online before Monday with minimal reprogramming.

Related or Supporting Products

• Honeywell Saia PCD4.Mxxx CPU base units – Required host controllers for PCD4 I/O; pick CPU performance and memory to match your application.
• Honeywell Saia PCD4.D2xx digital output modules – Complementary DO modules if you also need relay or transistor outputs.
• Honeywell Saia PCD4.A1xx analog input modules – For temperature and process signals alongside digital inputs.
• Honeywell Saia PCD4.F1xx communication/interface modules – Add fieldbus or serial connectivity where needed.
• Migration option: Honeywell Saia PCD3 I/O – Newer platform with expanded diagnostics and lifecycle runway; use with an approved migration path when upgrading from PCD4.

Installation & Maintenance

• Cabinet & mounting – Install on a PCD4 backplane inside an IP-rated control cabinet. Keep at least moderate airflow; avoid mounting near high-heat sources.
• Power & wiring – Use a clean 24 VDC field supply for inputs. Separate I/O and power wiring from high-voltage lines. Shield and ground long sensor runs to reduce noise.
• Fusing & protection – Protect the 24 VDC field supply with appropriately rated fuses or circuit breakers. Add surge protection where inductive loads are present.
• Commissioning – Verify input polarity and common wiring; use the front LEDs to check channel state before starting the process.
• Maintenance – Periodically re-torque terminals, remove dust with dry air, and check for loose commons. Firmware is handled by the host PLC; keep controller firmware and project backups current.
• Environment – Typically 0…55 °C, non-condensing humidity. If nearby VFDs or contactors cause noise, consider additional ferrites or shield terminations.

Quality & Certifications

• CE compliant (EMC and LVD, typical for industrial control modules)
• UL (industrial control equipment), region-dependent
• RoHS compliant
• Manufacturer’s warranty: 12 months (365 days)

If you can share the exact D1xx sub-variant (channel count and input type), I can confirm the detailed electrical specs and suggest a drop-in alternative if lead time is critical.
