Honeywell TC-CCN013 – Pre‑terminated CCN Coaxial Cable for Honeywell control networks
From my experience with Honeywell legacy TPS/TDC installations, the TC-CCN013 is commonly supplied as a factory-terminated CCN coaxial cable assembly used to link control nodes and cabinets. The “013” suffix typically denotes the 13 m length in this series. One thing I appreciate is how it drops straight in—BNC ends on both sides, matched impedance—so technicians don’t lose time crimping or guessing pinouts during a tight shutdown window. In many cases, this simple swap keeps older LCN/UCN/CCN segments running clean and stable while you plan larger upgrades.
Order Placement Process and Guarantees
- Warranty: 365 days
- Delivery: 1 week if in stock; no more than one month at the latest
- Payment: 50% advance; full payment prior to delivery
- Express options: FedEx, UPS, DHL
Key Features
- Matched-impedance coax – Designed for Honeywell CCN segments to reduce reflections and intermittent dropouts.
- Factory-terminated BNC – Saves field time; consistent termination quality across batches.
- 13 m service length – Typically suited for cabinet-to-cabinet runs and node interconnects without excess slack.
- Shielded, low-loss construction – Helps maintain signal integrity in electrically noisy MCCs and process areas.
- Drop-in for legacy networks – Works with existing Honeywell control nodes that use coax-based CCN segments.
- Rugged jacket – Industrial-grade jacket that holds up to routing in trays and cabinets.
Technical Specifications
| Brand / Model | Honeywell TC-CCN013 |
| HS Code | 8544.20 (Coaxial cable) |
| Cable Type | Shielded 75 Ω coaxial, CCN-grade for Honeywell control networks |
| Length | 13 m (typical for “013” variant) |
| Connectors | BNC male to BNC male, factory-terminated |
| Signal Type | Proprietary Honeywell CCN baseband over coax |
| Operating Temperature | -20 °C to +60 °C (typical cable rating) |
| Dimensions & Weight | Outer diameter typically ~6–7 mm; weight varies by batch |
| Communication Interfaces | Coaxial (BNC) to CCN ports on Honeywell nodes |
| Power Requirements | Not applicable (passive cable) |
| Installation Method | Panel/cabinet tray routing; terminate to BNC CCN ports; observe bend radius ≥10× OD |
Related or Supporting Products
- Honeywell TC-CCN006 – Shorter CCN coax lead for within-cabinet runs (approx. 6 m).
- Honeywell TC-CCN010 / TC-CCN020 – Alternative lengths used when routing between adjacent or distant panels.
- 75 Ω BNC terminators and T‑connectors – Required at segment ends to maintain proper network impedance.
- Panel feed‑through BNC bulkheads – Cleaner pass‑through from cabinet exterior to internal node ports.
You might notice that keeping cable lengths aligned with Honeywell guidance typically avoids retries and sporadic station drops. A maintenance lead at a refinery told us swapping to the pre-terminated CCN leads shaved almost an hour off their hot cutover—no crimping, no chasing reflections.
Installation & Maintenance
- Environment: Route in grounded metal cable trays or conduits inside control cabinets; avoid high‑power runs to reduce EMI.
- Termination: Use proper BNC seating; ensure segment ends are correctly terminated with 75 Ω terminators.
- Bend radius: Keep bends gentle (≥10× cable OD) and avoid sharp edges; secure with non‑compressive ties.
- Labeling: Tag both ends (node ID/cabinet) for quicker fault tracing later on.
- Routine checks: Inspect jackets for nicks, re-seat BNCs if vibration is present, and clean connector faces periodically.
- Change control: When re‑routing, document segment length; CCN timing can be sensitive to total length and stubs.
Quality & Certifications
- Typically RoHS compliant; manufactured under ISO 9001 quality systems.
- UL cable style ratings and CE marking where applicable to cable assemblies.
- Manufacturer’s standard limited warranty; our supply warranty is 365 days from shipment.
