INDRAMAT MAC093B-0-OS-2-C130-A-0S005 – AC Servo Motor for Precise, Reliable Motion on Legacy and Retrofit Lines

The INDRAMAT MAC093B-0-OS-2-C130-A-0S005 is a MAC series AC servo motor that typically pairs with classic INDRAMAT drive systems on packaging, printing, woodworking, and general automation machinery. One thing I appreciate is how the 093 frame with the “B” length hits a sweet spot: compact enough for tight machines, yet strong and smooth for continuous duty. The “C130” flange centering (130 mm) makes swaps straightforward on many European-built machines, so replacement downtime is kept short in most cases.

Company’s Order Placement Process and Guarantees

• Warranty: 365 days
• Delivery time: 1 week for in-stock; no more than one month at the latest
• Payment: 50% advance payment, full payment for delivery
• Express delivery: FedEx, UPS, DHL

Key Features

• MAC093B frame and length: A proven, medium-frame motor that balances footprint and torque for 24/7 motion profiles.
• C130 flange centering: 130 mm centering diameter for quick drop-in alignment on existing mounts and gearboxes.
• Smooth, low-cogging operation: From my experience, these motors run quietly and keep velocity ripple low for better surface finish and registration.
• Feedback-ready design: Uses dedicated power and feedback connectors (resolver/tacho variant depending on the exact suffix) with integrated thermal protection.
• Robust sealing: Typically up to IP65 when mated with the correct connector set—suitable for dusty shop floors and light washdown zones.
• Continuous-duty capability: Built for S1 operation where stable speed and steady torque are essential.
• Service-friendly: Standard flange interface and accessible connectors simplify field replacement and cable routing.

Technical Specifications

Related or Supporting Products

• INDRAMAT MAC093A series: Same frame with shorter active length; typically lower continuous torque. A good fit when space is tight.
• INDRAMAT MAC093C series: Same frame with longer active length; typically higher continuous torque for heavier loads.
• INDRAMAT MAC112 series: Larger frame option when more torque is required without changing the drive family.
• Drive pairing (legacy): Compatible with INDRAMAT TDM/KDV systems and, in many cases, selected legacy drive modules when feedback options match. Please verify against the exact suffix and drive feedback card.
• Cable sets & accessories: Motor power cable set, feedback cable set, mating connector kit, shaft key, and optional holding brake variants (model-dependent).

Installation & Maintenance

• Mounting & environment: Use a rigid B5 flange surface with proper centering. Maintain ambient 0–40 °C with adequate airflow; avoid direct coolant spray unless fully protected.
• Wiring practices: Use shielded motor and feedback cables, correct pinouts, and proper strain relief. Ground the motor and cable shields at the drive end to reduce EMI.
• Alignment: Align coupling carefully; excessive misalignment accelerates bearing wear. You might notice less noise and heat when alignment is right.
• Safety: Lockout/tagout before servicing. Never disconnect connectors under power. Confirm brake status before manual rotation if the motor variant includes a brake.
• Routine maintenance: Inspect connectors for ingress and oxidation, clean surfaces and fins, check for abnormal bearing noise or vibration, and verify insulation resistance during planned outages. If a drive is replaced, a quick servo tuning check typically helps restore original performance.
• Spare strategy: Keeping one identical MAC093B unit on the shelf seems to be the most cost-effective approach for lines where uptime is critical.

Quality & Certifications

• Certifications: CE conformity; UL recognition and RoHS applicability may depend on the production lot and regional requirements.
• Protection class: Up to IP65 with correctly mated connectors (typical for MAC series).
• Warranty: 365 days (our supply policy). Manufacturer’s standard policies for this family are typically 12 months.

If you’re upgrading or replacing an existing MAC093B on a legacy line, share the full suffix and your drive model; I can quickly validate feedback compatibility and cable sets so installation goes smoothly the first time.
