Description

Parameter description
Model: IS200EPSMG1AEC
Power supply type: DC input or AC input, which needs to be confirmed according to specific configuration
Input voltage range: AC: 100-240V (±10%), 50/60Hz; DC: 24V (±15%)
Output voltage: 5V DC, 12V DC, 24V DC, etc. (Multi-channel output)
Output current: The total output current can reach 50A (depending on the distribution of each voltage channel)
Efficiency: Typical value ≥90% (at full load)
Operating temperature: -40°C to +85°C (industrial-grade wide-temperature design
Humidity: 5% to 95% (no condensation)
Certification: Comply with industrial standards (such as IEC 61000, UL 508, CE, etc.)

It is mainly used to provide a stable DC power supply for other modules in the Mark VIe system (such as the processor module, I/O module, etc.), and supports redundant configuration to ensure the reliability of the system power supply.
Voltage conversion and monitoring
The IS200EPSMG1AEC converts the input power supply (usually external power supply) into the voltage required by each module (such as 5V, 12V, 24V, etc.), and monitors the power supply status in real time. It is equipped with overvoltage and undervoltage protection functions.
System redundancy support: The IS200EPSMG1AEC can be paired with another power module to achieve power redundancy and prevent system downtime caused by a single point of failure.

2. Hardware characteristics
Input power supply:
Supports direct current (DC) or alternating current (AC) input, depending on the model configuration (please refer to the official manual for confirmation).
Input voltage range: Usually 100-240V AC or 24V DC (industrial-grade wide voltage design).
Output power supply:
Multi-channel DC output, powering different modules (such as 5V DC for logic circuits and 24V DC for I/O signals).
Output power: According to the module design, the output power of a single module can reach several hundred watts.
Interface and indicator light:
Power input interface: Used for connecting to external power supply lines.
Power output interface: Connected to other modules of the system via the backplane or cable.
Status indicator light:
Power OK: Green LED, indicating that the input power supply and the module are working properly.
Fault: Red LED, indicating overvoltage, undervoltage or internal fault.
Redundancy Status: Indicates the working status of the primary and backup power modules.
Mechanical Design
It conforms to the standard rack installation dimensions of the Mark VIe system and supports rail or backplane installation.
Compact structure, suitable for high-density deployment in industrial environments.

4. Application Scenarios
Electric power industry
Power supply guarantee for gas turbine and steam turbine control systems to ensure stable power supply in high-temperature and high-vibration environments.
Industrial Automation
The power supply for the control system of large-scale units (such as compressors and pump equipment) supports continuous operation for 24 hours.
Field of process control
In scenarios with extremely high reliability requirements such as petrochemicals and metallurgy, a redundant architecture is employed to enhance system availability.
