Mark VI | IS200AEPAH1BKE IS215WEPAH2BB | Analog input/output card

Technical Specifications

  • Part Number: IS200AEPAH1BKE IS215WEPAH2BB
  • Manufacturer: General Electric Industrial Systems
  • Series: Mark VI
  • Board Type: Printed Circuit Board
  • Full Revision: IS215WEPAH2BB
  • COM Ports: 3; COM1, COM2, and micro-miniature 9-pin socket D connector
  • Ethernet Interfaces: 10BaseT/AUI connector
  • Manual: GEP-9145
  • Relative Humidity: 10-95%, non-condensing
  • Shock: maximum 10G, non-operating

Description



1. IS200AEPAH1BKE (GE Mark VIe Series)
Product positioning and functions
Affiliated system: GE Mark VIe Control System (used for the control of large equipment such as gas turbines, steam turbines, compressors, etc.).
Module type: Analog I/O Panel Assembly.

Core functions:
The IS200AEPAH1BKE IS215WEPAH2BB supports the acquisition and output of 4-20mA current signals or 0-10V voltage signals.
It may include a thermocouple/RTD temperature input channel, suitable for the connection of sensors such as temperature, pressure and flow.
It has signal isolation and filtering functions, and strong anti-interference ability (conforming to industrial electromagnetic compatibility standards).

2. Technical Specifications (Typical Values)
Parameter details
The number of channels is usually 8 to 16 analog input/output channels (for specific details, please refer to the manual).
Resolution: 16-bit ADC/DAC, accuracy: approximately ±0.01% FS.
Power supply: 24VDC (redundant design, supporting dual power input).
The communication interface communicates with the Mark VIe master module through the SERCANS bus, and the transmission rate is approximately 10 Mbps.
Operating temperature: -40°C to +70°C (extended models can reach -55°C to +85°C).

3. Application Scenarios
Power plant: IS200AEPAH1BKE IS215WEPAH2BB collects analog signals such as turbine bearing temperature and lubricating oil pressure.
Petrochemical industry: Connect flow transmitters and level gauges to achieve closed-loop regulation of process control.
Ii. IS215WEPAH2BB (Upgraded Version of GE Mark VIe)

Product positioning and functions
Affiliated system: GE Mark VIe+ or Mark 7e system (an upgraded version of Mark VIe, enhancing digitalization and cybersecurity capabilities).
Module type: Intelligent analog I/O card (based on the technological evolution of the IS200 series).


Core Upgrade:
Support: HART communication protocol (intelligent transmitter parameters can be remotely configured).
Integrate advanced diagnostic functions (such as channel impedance monitoring and signal quality assessment).
Optimize the EMC anti-interference capability to adapt to harsher industrial environments.
2. Technical Specifications (Compared with IS200AEPAH1BKE)

Parameters: IS200AEPAH1BKE IS215WEPAH2BB
Communication protocol: SERCANS bus, SERCANS-Ⅲ bus (Higher bandwidth)
Diagnostic function: Basic condition monitoring supports predictive maintenance (such as sensor aging early warning)
Software compatibility: The Mark VIe system must be compatible with Mark VIe+ and Mark 7e
Physical interface: DB9 connector reinforced M12 connector (stronger shock resistance)
