Description
Model: IS200AEPCH1BAA
Mechanical characteristics:
Dimensions: 177.8mm (height) × 48.26mm (width) × 228.6mm (depth) (Conforming to the standard card size of Mark VI)
Input channel:
32-channel differential input (46 channels for the ABC version), supporting adaptive switching of voltage (±10V DC)/current (4-20mA) signals;
Resolution: 24-bit ADC, conversion rate ≥ 1000 SPS (sampling per second), meeting the requirements of dynamic signal acquisition;
Accuracy: ±0.05% FSR (full-scale error), temperature drift coefficient < 50 ppm/°C.
Signal conditioning
Built-in programmable gain amplifier (PGA), with a gain range of 1 to 1000 times;
Supports low-pass filtering (the cut-off frequency is adjustable from 10Hz to 1kHz) to suppress high-frequency noise.
2. Electrical and mechanical specifications
Power supply:
24V DC (±10%), typical power consumption 5W, supports redundant power input (dual power supply interfaces);
Surge protection: Complies with IEC 61000-4-5 standard and can withstand a surge impact of 2kV.
Communication interface:
Communicate with the main control module through the Mark VI backplane bus (RS-485 compatible), with a transmission rate of 1Mbps;
Supports hot plugging and is equipped with a reverse connection protection circuit.
Installation method: Vertically insert into the control cabinet frame, with guide slots and locking mechanisms.
3. Environmental adaptability
Operating temperature: -40°C to +70°C (wide temperature design, suitable for harsh industrial environments)
Protection grade: IP20 (installed inside the control cabinet), anti-vibration (conforming to IEC 60068-2-6 standard, 10-500Hz, 2g acceleration).
