Description



IS200DTAIH1ABB technical specification
Manufacturer: General Electric
Series: Mark VI Speedtronic
Functional component number: IS200DTAIH1ABB
Function description: Simplex analog input/output terminal board
Total number of revisions: 3 fixes
Backward compatibility: First and second revisions
Component type: Normal assembly

Function positioning: Process digital signals from industrial sites (such as switch quantities and logic signals), and achieve interaction between control systems and peripheral devices (such as sensors, actuators, and relays).

The IS200DTAIH1ABB is a module in the Mark VIe series turbine control system of General Electric (GE). It belongs to the digital input/output module (DI/O) and is mainly used in industrial turbines, energy systems and automation control scenarios to achieve the acquisition and control output of digital signals. The following is its detailed information:

Ii. Hardware Design and Interface
Appearance structure
Standard industrial control module size, compatible with GE Mark VIe system racks.
The front panel is usually equipped with status indicator lights (such as power, channel status, and fault alarm lights) to facilitate real-time monitoring of the module’s operating status.
The integrated connector on the back is used to connect with the system backplane bus (such as the data bus and power bus).
Input/output channel
Digital input (DI) : Supports multiple dry contact or wet contact inputs (such as switch status, button signals), has electrical isolation function, and strong anti-interference ability.
Digital Output (DO) : It provides multi-channel relay or solid-state relay output (such as controlling solenoid valves, contactors), and the output capacity varies depending on the model (usually 24V DC/2A or similar specifications).
Key interface
Power interface: Connect to the system power supply (such as 24V DC).
Signal interface: Connect to on-site equipment through terminal blocks or cables.
Bus interface: Communicate with the Mark VIe controller and transmit input/output data.

Frequently asked questions about IS200DTAIH1ABB
What does the conformal PCB coating include?

The conformal coating of the IS200DTAIH1ABB Simplex analog input/output terminal board is a thin layer of PCB protection with chemical applications, extending to the entire base PCB of the IS200DTAIH1ABB Simplex analog input/output terminal board device.
How is this IS200DTAIH1ABB Simplex Analog Input/Output Terminal Board device installed?

This IS200DTAIH1ABB simplex analog input/output terminal board product is installed on the DIN rail assembly because it has a plastic mounting back plate.
