Mark VI IS200JPDDG1AAA | IS200EGPAG1BCA Exciter Power Supply Module
Label ：Specification
Model NumberIS200JPDDG1AAA：
Brand： General Electric (GE)
Type ：Exciter Power Supply Module
Input Voltage ：125V DC (±10%)
Output Voltage ：+5V DC, +15V DC, +24V DC
Operating Temperature： 0°C to +65°C (no active cooling required)
Categories: GETags: IS200JPDDG1AAA
Description
As a key component in GE’s Mark VI series, the IS200JPDDG1AAA bridges the gap between electrical infrastructure and turbine control systems. Its primary role is to provide regulated power to critical subsystems, including field voltage/current modules and relay logic, while maintaining compatibility with redundant control architectures. This makes it ideal for mission-critical setups where downtime could result in significant operational losses. With a focus on durability and ease of integration, GE has designed the IS200JPDDG1AAA to meet the rigorous demands of modern industrial environments, offering a balance of advanced technology and practical engineering.
Whether deployed in standalone gas turbine systems or integrated into larger SCADA networks, the IS200JPDDG1AAA exemplifies GE’s commitment to innovation. Its ability to handle high input voltages (125V DC) and deliver precise outputs (+5V, +15V, +24V DC) ensures consistent performance across a wide range of applications. By prioritizing reliability and compatibility, GE has created a module that not only enhances turbine efficiency but also future-proofs industrial control systems against technological advancements.
Technical Highlights Table
| Label | Specification |
|---|---|
| ModeI | IS200JPDDG1AAA |
| Brand | General Electric (GE) |
| Type | Exciter Power Supply Module |
| Input Voltage | 125V DC (±10%) |
| Output Voltage | +5V DC, +15V DC, +24V DC |
| Operating Temperature | 0°C to +65°C (no active cooling required) |
| Communication Method | Ethernet, RS-485 |
| Mounting | DIN-rail or panel-mount (rack-compatible) |
| Weight | 0.9 kg (1.98 lbs) |
| Certifications | CE, UL 508, IEC 61131-2 compliant |
| Dimensions | 8.25 cm (H) x 4.15 cm (W) x 15 cm (D) |
| IP Rating | IP20 (indoor use, dust-protected) |
| Redundancy Support | Hot-swappable in dual or triple configurations |
Functional Strengths & Design Advantages
The GE IS200JPDDG1AAA stands out for its robust design and precision engineering, making it a leader in turbine control applications. Its dual-stage power conversion system—featuring a buck regulator and push-pull inverter—ensures stable voltage outputs even under fluctuating input conditions, minimizing the risk of system instability. Operators benefit from its high-efficiency thermal management, which eliminates the need for external cooling systems while maintaining optimal performance across its entire temperature range. This durability is further enhanced by industrial-grade components that resist electromagnetic interference and mechanical vibration, ensuring reliable operation in harsh environments like petrochemical plants or offshore platforms.
Interoperability is another key strength, as the module seamlessly integrates with GE’s Mark VI and Mark VIe systems, supporting both single and redundant control architectures. Its hot-swappable design allows for maintenance without powering down the entire turbine, reducing downtime during routine inspections or component replacement. The IS200JPDDG1AAA also features diagnostic capabilities that monitor voltage levels and system health in real-time, enabling predictive maintenance and reducing the likelihood of unexpected failures. By combining advanced power management with user-friendly diagnostics, GE has created a module that simplifies complex turbine control while maximizing operational efficiency.
Industrial Use Cases & Value Scenarios
In power generation facilities, the GE IS200JPDDG1AAA plays a pivotal role in stabilizing gas turbine operations. Its ability to deliver precise DC power to the EX2100 excitation system ensures consistent voltage regulation, critical for maintaining grid stability and optimizing energy output. For example, in a combined-cycle power plant, this module supports seamless transitions between load demands, reducing wear on turbine components and extending equipment lifespan. In oil and gas applications, the IS200PMCIH1AAA6BA00 is equally vital, providing reliable power to control systems in offshore platforms where environmental conditions are extreme and maintenance access is limited.
The module’s redundancy support is particularly valuable in mission-critical environments like nuclear power plants or large-scale industrial complexes. By enabling triple modular redundancy (TMR) configurations, it ensures continuous operation even if individual components fail, a feature that aligns with strict safety and reliability standards. Industrial managers also appreciate its role in reducing operational costs: the IS200JPDDG1AAA ’s energy-efficient design minimizes power waste, while its predictive diagnostics lower maintenance expenses by identifying issues before they escalate. Whether enhancing the performance of a utility-scale power plant or ensuring the safety of a chemical processing facility, this module delivers tangible value through its blend of precision, durability, and adaptability.
Compatible and Related Models
- IS200EPSMG1AED – A high-current variant optimized for heavy-duty turbine applications, offering enhanced power delivery.
- IS200EPSMG2ADC – A redundant power supply module designed for dual-control systems, ensuring zero downtime during component failure.
- IS200ERIOH1AAA – A companion I/O module for Mark VI systems, enabling seamless integration with sensors and actuators.
- IS200EROCH1ABB – A communication hub module that interfaces with the IS200PMCIH1AAA6BA00 to support remote monitoring and diagnostics.
- IS200JPDDG1AAA – A compact power distribution module for smaller turbine setups, sharing the same software ecosystem.
- IS200TVBAH2ACC – A thermal management module that complements the IS200JPDDG1AAA in high-temperature environments.
| GE | IS200FOSBH1A |
| GE | IS200FOSAG1A |
| GE | IS200EXIBG1A |
| GE | IS200EXCSG1A |
| GE | IS200ESELH1A |
| GE | IS200ERSCG2A |
| GE | IS200ERRRH1A |
| GE | IS200ERRBG1A |
| GE | IS200EROCHIA |
| GE | IS200EROCH1ADD |
| GE | IS200EROCH1ABB |
