Description

As a core component of GE’s Mark VI series, the IS200JPDMG1ACC S1AT005 bridges the gap between power sources and control logic, supporting both simplex and triple modular redundant (TMR) configurations. Its primary role is to distribute 220V AC power to downstream modules, including I/O cards, communication processors, and safety systems, while monitoring voltage levels and detecting faults in real-time. This makes it ideal for applications where downtime could result in significant losses, such as combined-cycle power plants or offshore platforms. With a focus on durability and ease of integration, GE has designed the IS200JPDMG1ACC S1AT005  to meet the rigorous demands of modern industrial environments, offering a balance of advanced technology and practical engineering.

Whether deployed in standalone turbine systems or integrated into larger SCADA networks, the GE IS200JPDMG1ACC S1AT005  exemplifies GE’s commitment to innovation. Its dual-terminal block design—featuring 18 screw terminals for secure connections—ensures seamless integration with a wide range of power sources and field devices. By prioritizing electromagnetic interference (EMI) protection and thermal stability, GE has created a module that not only enhances power reliability but also future-proofs industrial control systems against technological advancements.

Technical Highlights Table
Label specification parameters
Model :IS200JPDMG1ACC S1AT005
Brand: General Electric (GE)
Type: Power Distribution module
Input voltage: 220V AC (±10%)
Output channels :18 DC outputs (4-20mA, 0-10V optional)
Operating temperature: -20°C to +60°C (natural convection cooling)
Protection grade: IP20 (For indoor use, dust-proof design)
EMI filtering: Passive electromagnetic interference filter
Installation method: Rack-mounted (reinforced with metal frame)
Dimensions :23.1 cm (length) x 14.3 cm (width) x 2.5 cm (depth)
Certified to comply with CE, UL 508 and IEC 61131-2
Redundancy support: Supports dual redundancy or triple redundancy configuration
Protection functions: overvoltage, undervoltage and short-circuit protection

Functional advantages and design highlights
The GE IS200JPDMG1ACC S1AT005  stands out for its robust design and precision engineering, making it a leader in power distribution applications. Its passive EMI filtering system effectively mitigates high-frequency noise, ensuring stable power output even in electrically noisy environments like petrochemical plants or steel mills. Operators benefit from its modular architecture, which allows for easy expansion of power channels without disrupting existing systems. This durability is further enhanced by industrial-grade components that resist mechanical vibration and temperature fluctuations, ensuring reliable operation in extreme conditions.



Interoperability is another key strength, as the module seamlessly integrates with GE’s Mark VI and Mark VIe systems, supporting both analog and digital signal protocols. Its hot-swappable design allows for maintenance without powering down the entire turbine, reducing downtime during routine inspections or component replacement. The IS200JPDMG1ACC S1AT005 also features configurable jumper switches that enable users to adapt the module to specific power requirements, such as adjusting current limits for sensitive equipment. By combining advanced power management with user-friendly diagnostics, GE has created a module that simplifies complex power distribution tasks while maximizing operational efficiency.
