Description

As a key component of the Mark VIe series, the IS200TBAIH1CCC is engineered to handle the rigorous demands of industrial operations. It supports up to 10 analog inputs (configurable for 2/3/4-wire or externally powered transmitters) and 2 analog outputs, with input spans ranging from 1–5 V DC (for 4–20 mA current signals) and output ranges of 0–20 mA or 0–200 mA. This versatility allows it to interface with a wide array of sensors and actuators, making it suitable for both simplex and triple modular redundant (TMR) configurations—a critical feature for systems where downtime is not an option.

Technical Highlights Table
Label ：Specification
Model Number： IS200TBAIH1CCC
Brand： General Electric (GE)
Type ：Analog Input/Output Terminal Board
Input Voltage ：24 V DC (19.2–28.8 V DC)
Operating Temp： 30°C to 65°C (86°F to 149°F)
Communication Method： Proprietary Mark VIe protocols
Mounting： DIN rail (TS 35/7.5 or TS 35/15)
Weight： 630–650 g
Certifications ：CE, UL, cUL, ATEX (hazardous areas)
Dimensions：10.16 cm (W) x 33.02 cm (H) x 11.5 cm (D)
IP Rating： IP20 (indoor use, dust-protected)
Protocols Supported ：Modbus TCP, EtherNet/IP
Functional Strengths & Design Advantages

The IS200TBAIH1CCC excels in delivering high-accuracy signal conditioning and noise immunity, thanks to its specialized circuitry that suppresses surges and high-frequency interference. This ensures reliable data acquisition even in electrically noisy environments common in industrial settings. Its simplex or TMR configuration enhances system resilience by distributing input signals across redundant control paths, minimizing the risk of single-point failures.

In the oil and gas sector, the module is deployed in compressor stations to manage pressure and flow dynamics, ensuring safe and efficient gas transmission. Its TMR capability is particularly valuable in offshore platforms, where system redundancy is critical for continuous operation. By integrating with GE’s Mark VIe system, the IS200TBAIH1CCC enables predictive maintenance through real-time diagnostics, flagging potential issues before they escalate.

Compatible and Related Models
IS420PUAAH1A – A versatile I/O module for Mark VIe systems, supporting mixed analog/digital signals.
IS220PSCAH1A – A serial communication module for Modbus integration, enhancing connectivity with third-party devices.
IS200TCATH1ABA – A temperature/pressure transmitter module for turbine monitoring.

IS200WETCH1A – A wind turbine control module compatible with Mark VIe systems.
IS215UCVEM09B – A PC control module for advanced turbine management.
Setup & Service Guidance
Installing the IS200TBAIH1CCC involves securing it to a DIN rail in a well-ventilated control cabinet, ensuring proper airflow to maintain optimal operating temperatures. Use shielded cables for signal connections to minimize electromagnetic interference, and ground the module correctly to prevent voltage spikes. For TMR configurations, follow GE’s guidelines to synchronize redundant channels and verify signal distribution.
